Rotork YTC YT-320P1 YT-320P2 YT-320P3 YT-320P4 Aluminum Volume Booster Relays

Product Details:

Place of Origin:	Korea, China
Brand Name:	Rotork, YTC, AIRWOLF or OEM
Model Number:	YT-320P1, YT-320P2, YT-320P3, YT-320P4

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	79-249USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Order Codes:	YT-320P1, YT-320P2, YT-320P3, YT-320P4	Housing Material:	Aluminum
Max. Supply Pressure:	1MPa	Max. Signal / Output Pressure:	0.7MPa
Supply / Output Connection:	1/2 Rc	Signal Connection:	1/4 Rc
Working Temperature Range:	-20~70℃, -20~ 120℃, -40~70℃, -60~70℃	Function:	Pressure Amplification, Flow Capacity Increase
Highlight:	Rotork YT-320P aluminum volume booster , YT-320P pneumatic volume booster relay , aluminum volume booster with warranty

Rotork YTC YT-320P1 YT-320P2 YT-320P3 YT-320P4 Aluminum Volume Booster Relays

Volume booster relay, YT-300 / 305 / 310 / 315 / 320 / 325, is used in pneumatic control valve which receives the output pressure signal from positioner and supply air pressure to actuator to reduce opening and closing time of the valve.

Order Codes:

Item Code	Supply / Output Connection	Signal Connection
YT-320P1	1/2 Rc	1/4 Rc
YT-320P2	1/2 Rc	1/4 Rc
YT-320P3	1/2 Rc	1/4 Rc
YT-320P4	1/2 Rc	1/4 Rc

Specification:

Model						YT-300 YT-305	YT-320 YT-325	YT-310 YT-315
Max. Supply Pressure						1 MPa(10 bar)
Max. Signal/ Output Pressure						0.7 MPa(7 bar)
Signal/ Output Pressure Ratio						1:1
Flow Capacity (Cv)		Exhaust				1.32	2.08	5.24
Flow Capacity (Cv)		Output				1.19	2.72	4.91
Supply/ Output Connection Signal Connection				YT-3x0		Rc 1/4 or 1/4 NPT	Rc 1/2 or 1/2 NPT	3/4 NPT 1/4 NPT
				YT-3x5		1/4 NPT	1/2 NPT
				YT-3x5		1/4 NPT
Linearity						±1%F.S.
Ambient Temperature						Standard Temp.:-20 to 70°C(-4 to 158°F)
						High Temp.:-20 to 120°C(-4 to 248°F)
						Low Temp.:-40 to 70°C(-40 to 158°F) Arctic Temp.:-60 to 70°C(-76 to 158°F)
Housing Material	YT-300,YT-320,YT-310					Aluminum
Housing Material	YT-305,YT-325,YT-315					Stainless Steel 316
Weight	YT-300		YT-320		YT-310	0.51 kg(1.1 lb)	0.77 kg(1.7 lb)	1.9 kg(4.2 lb)
Weight	YT-305		YT-325		YT-315	1.4 kg(3 lb)	1.9 kg(4.2 lb)	4.6 kg(10.1 lb)

Parts and Assembly:

Dimension:

Flow Characteristics:
