061B000066 061B000166 061B000266 DANFOSS Pressure Switch MBC5000/5100

Product Details:

Place of Origin:	Poland
Brand Name:	DANFOSS, AIRWOLF or OEM
Model Number:	061B000066, 061B000166, 061B000266

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	130-190USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	Western Union,T/T,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

061B000066 061B000166 061B000266 DANFOSS Pressure Switch MBC5000/5100

MBC pressure switches are used in industrial and marine applications where space and reliability are the most important features. MBCs are compact pressure switches, designed according to our block design to survive in the harsh conditions known from machine rooms onboard ships. MBCs have high vibration resistance and MBC 5100 features all common marine approvals. The fixed, but low differential guarantees accurate monitoring of critical pressures. MBV test valves can be delivered as standard option for MBC.

Order Codes:

Item Code	Type
061B000066	MBC 5100
061B000166	MBC 5100
061B000266	MBC 5100

Specification:

Performance
Repeatability	Bellows versions	±0.2% FS (typ.) ±0.5% FS (max.)
	Diaphragm versions	±0.5% FS (typ.) ±1.0% FS (max.)
	Piston versions	±1.0% FS (typ.) ±1.0% FS (max.)
Max. switch frequency		10/min (0.16 Hz)
Differential		See Figure: Customized types
Permissible operating pressure		See Figure: Customized types
Burst pressure		See Figure: Customized types
Lifetime	Mechanical for diaphragm and bellows Mechanical for piston type Electrical at max. contact load	>400,000 cycles >1 million cycles >100,000 cycles

Electrical specifications
Switch	Utilization category	SPDT
Contact load	AC 15	0.5 A, 250 V
Contact load	DC 13	12 W, 125 V

Mechanical characteristics
Pressure connection	Standard	G 1/4 female (ISO 228-1) or flange
Pressure connection	Option	See specification form Figure: Customized types
Electrical connection	Plug	DIN 43650, Pg 9 / Pg 11 / M20
Wetted parts material	Housing	Anodized AlMgSi1, AW-6082T6
	Housing	Stainless steel 1.4306 (18/8), acc. to EN10088-3
	Bellows	Stainless steel 1.4306 (18/8), acc. to EN10088-2
	Diaphragm	FKM
	Piston	Stainless steel 1.4028 (3H13), acc. to EN10088-2
	O-ring	NBR
	Hole plug (flange version)	Nickel plated brass or zinc plated steel
	Seal (piston version)	Turcon T05
Enclosure material	Housing	Anodized AlMgSi1, AW-6082T6
	Plug fixture	Glass filled polyamid, PA 6.6
	Contact system	Silver (AG) micro profile
Net weight		0.25 kg

Environmental conditions:

Temperature	Operation	Bellows versions	-40 – 85 °C
		Diaphragm versions	-10 – 85 °C
		Piston versions	-40 – 85 °C
	Transport	Bellows versions	-50 – 85 °C
		Diaphragm versions	-50 – 85 °C
		Piston versions	-40 – 85 °C
Enclosure			IP65, EN 60529
Vibration stability	Sinusoidal	20 g, 25 – 2 kHz	EN 60068-2-6
Vibration stability	Sinusoidal	Piston type 4.4 g, 25 – 200 Hz	IEC 60068-2-27

Dimensions:

061B000066 061B000166 061B000266 DANFOSS Pressure Switch MBC5000/5100
