Name: YT-320N1 YT-320N2 YT-320N3 YT-320N4 Rotork YTC Aluminum Volume Booster Relays
Brand: Airwolf Automation
SKU: YT-320N1, YT-320N2, YT-320N3, YT-320N4
Price: 164.00 USD
Availability: InStock

Home Products Pneumatic System Components

YT-320N1 YT-320N2 YT-320N3 YT-320N4 Rotork YTC Aluminum Volume Booster Relays

Product Details:

Place of Origin:	Korea, China
Brand Name:	Rotork, YTC, AIRWOLF or OEM
Model Number:	YT-320N1, YT-320N2, YT-320N3, YT-320N4

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	79-249USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Order Codes:	YT-320N1, YT-320N2, YT-320N3, YT-320N4	Housing Material:	Aluminum
Max. Supply Pressure:	1MPa	Max. Signal / Output Pressure:	0.7MPa
Supply / Output Connection:	1/2 NPT	Signal Connection:	1/4 NPT
Working Temperature Range:	-20~70℃, -20~ 120℃, -40~70℃, -60~70℃	Function:	Pressure Amplification, Flow Capacity Increase
Highlight:	Rotork YTC aluminum volume booster , YT-320N pneumatic booster relay , aluminum pneumatic system relay

YT-320N1 YT-320N2 YT-320N3 YT-320N4 Rotork YTC Aluminum Volume Booster Relays

Main Features and Functions
➢ Provides pneumatic pressure with stable 1:1 pressure ratio, excellent speed and accuracy.
➢ By-pass control enhances safety of the control valve operation.
➢ Sensitive response to small input changes of the positioner to deliver accurate and fast output to
the actuator.
➢ SIL2 certified.(For more information, see SIL Safety Instruction on homepage)

Order Codes:

Item Code	Supply / Output Connection	Signal Connection
YT-320N1	1/2 NPT	1/4 NPT
YT-320N2	1/2 NPT	1/4 NPT
YT-320N3	1/2 NPT	1/4 NPT
YT-320N4	1/2 NPT	1/4 NPT

Specification:

Model						YT-300 YT-305	YT-320 YT-325	YT-310 YT-315
Max. Supply Pressure						1 MPa(10 bar)
Max. Signal/ Output Pressure						0.7 MPa(7 bar)
Signal/ Output Pressure Ratio						1:1
Flow Capacity (Cv)		Exhaust				1.32	2.08	5.24
Flow Capacity (Cv)		Output				1.19	2.72	4.91
Supply/ Output Connection Signal Connection				YT-3x0		Rc 1/4 or 1/4 NPT	Rc 1/2 or 1/2 NPT	3/4 NPT 1/4 NPT
				YT-3x5		1/4 NPT	1/2 NPT
				YT-3x5		1/4 NPT
Linearity						±1%F.S.
Ambient Temperature						Standard Temp.:-20 to 70°C(-4 to 158°F)
						High Temp.:-20 to 120°C(-4 to 248°F)
						Low Temp.:-40 to 70°C(-40 to 158°F) Arctic Temp.:-60 to 70°C(-76 to 158°F)
Housing Material	YT-300,YT-320,YT-310					Aluminum
Housing Material	YT-305,YT-325,YT-315					Stainless Steel 316
Weight	YT-300		YT-320		YT-310	0.51 kg(1.1 lb)	0.77 kg(1.7 lb)	1.9 kg(4.2 lb)
Weight	YT-305		YT-325		YT-315	1.4 kg(3 lb)	1.9 kg(4.2 lb)	4.6 kg(10.1 lb)

Parts and Assembly:

Dimension:

Flow Characteristics:

Our Company:

Airwolf Automation is a world-renowned supply chain management company. A complete supply chain with 500,000 industrial parts can be supplied to 160 countries.

More than a thousand cooperative brands, super supply chain management ability, to ensure the fastest speed to meet your procurement needs.

Delivery:

1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.

Q&A:

1. Q: Do you provide warranty for the goods?

A: Yes, we provide warranty for all the goods from us.

2. Q: Could seek best provide technology support?

A: We're in this field more than 10 years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.

3. Q: Does seek best keeps goods in stock or only trading?

A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.

4. Q:How about the terms of payment?

A:Generally through T/T and Paypal,Western Union also accept.
