Rotork YTC YT-305N1 YT-305N2 YT-305N3 YT-305N4 Stainless Steel 316 Volume Booster Relays
Basic Properties
Place of Origin:Korea, China
Brand Name:Rotork, YTC, AIRWOLF or OEM
Model Number:YT-305N1, YT-305N2, YT-305N3, YT-305N4
Trading Properties
Minimum Order Quantity:1 piece
Price:79-249USD
Standard Packaging:Boxes, Cartons, Pallets, Plastic bags
Delivery Time:1-7 work days
Payment Terms:T/T,Western Union,Paypal
Supply Ability:1000 pcs per week
Specifications
| Order Codes: | YT-305N1, YT-305N2, YT-305N3, YT-305N4 | Housing Material: | Stainless Steel 316 |
|---|---|---|---|
| Max. Supply Pressure: | 1MPa | Max. Signal / Output Pressure: | 0.7MPa |
| Supply / Output Connection: | 1/4 NPT | Signal Connection: | 1/4 NPT |
| Working Temperature Range: | -20~70℃, -20~ 120℃, -40~70℃, -60~70℃ | Function: | Pressure Amplification, Flow Capacity Increase |
| Highlight | Stainless Steel 316 volume booster relay,Rotork YTC pneumatic volume booster,YT-305N series pneumatic relay |
||
Product Description
Rotork YTC YT-305N1 YT-305N2 YT-305N3 YT-305N4 Stainless Steel 316 Volume Booster Relays
Volume booster relay, YT-300 / 305 / 310 / 315 / 320 / 325, is used in pneumatic control valve which receives the output pressure signal from positioner and supply air pressure to actuator to reduce opening and closing time of the valve.
Order Codes:
| Item Code | Supply / Output Connection | Signal Connection |
|---|---|---|
| YT-305N1 | 1/4 NPT | 1/4 NPT |
| YT-305N2 | 1/4 NPT | 1/4 NPT |
| YT-305N3 | 1/4 NPT | 1/4 NPT |
| YT-305N4 | 1/4 NPT | 1/4 NPT |
Specification:
| Model | YT-300 YT-305 |
YT-320 YT-325 |
YT-310 YT-315 |
|||||
|---|---|---|---|---|---|---|---|---|
| Max. Supply Pressure | 1 MPa(10 bar) | |||||||
| Max. Signal/ Output Pressure | 0.7 MPa(7 bar) | |||||||
| Signal/ Output Pressure Ratio | 1:1 | |||||||
| Flow Capacity (Cv) |
Exhaust | 1.32 | 2.08 | 5.24 | ||||
| Output | 1.19 | 2.72 | 4.91 | |||||
| Supply/ Output Connection Signal Connection |
YT-3x0 | Rc 1/4 or 1/4 NPT |
Rc 1/2 or 1/2 NPT |
3/4 NPT 1/4 NPT |
||||
| YT-3x5 | 1/4 NPT | 1/2 NPT | ||||||
| YT-3x5 | 1/4 NPT | |||||||
| Linearity | ±1%F.S. | |||||||
| Ambient Temperature | Standard Temp.:-20 to 70°C(-4 to 158°F) | |||||||
| High Temp.:-20 to 120°C(-4 to 248°F) | ||||||||
| Low Temp.:-40 to 70°C(-40 to 158°F) Arctic Temp.:-60 to 70°C(-76 to 158°F) |
||||||||
| Housing Material |
YT-300,YT-320,YT-310 | Aluminum | ||||||
| YT-305,YT-325,YT-315 | Stainless Steel 316 | |||||||
| Weight | YT-300 | YT-320 | YT-310 | 0.51 kg(1.1 lb) | 0.77 kg(1.7 lb) | 1.9 kg(4.2 lb) | ||
| YT-305 | YT-325 | YT-315 | 1.4 kg(3 lb) | 1.9 kg(4.2 lb) | 4.6 kg(10.1 lb) | |||
Parts and Assembly:
Dimension:
Flow Characteristics:
Our Company:
Airwolf Automation is a world-renowned supply chain management company. A complete supply chain with 500,000 industrial parts can be supplied to 160 countries.
More than a thousand cooperative brands, super supply chain management ability, to ensure the fastest speed to meet your procurement needs.
Delivery:
- 1. If the products we have in store, we will send it out ASAP after payment.
- 2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
- 3. Also we can send by your delivery acount if you want.
- 4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.
Q&A:
1. Q: Do you provide warranty for the goods?
A: Yes, we provide warranty for all the goods from us.
2. Q: Could seek best provide technology support?
A: We're in this field more than 10 years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.
3. Q: Does seek best keeps goods in stock or only trading?
A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.
4. Q:How about the terms of payment?
A:Generally through T/T and Paypal,Western Union also accept.
