AIRTAC 4A430C-15, 4A430E-15, 4A430P-15 4A400 Series 5/3 way Air Valve 1/4" 3/8"
The AIRTAC 4A400 Series 5/3 Air Valve is a pneumatically operated directional control valve designed for robust industrial applications. It features a durable aluminum alloy body and a sliding column structure that ensures excellent sealing and highly sensitive response. This 5-port, 3-position valve is notable for offering three distinct center functions (models suffixed with C, E, and P) to provide flexibility in controlling double-acting actuators, such as holding, exhausting, or pressurizing a cylinder in its mid-position. It operates within a pressure range of 0.15 to 0.8 MPa, can function in temperatures from -20°C to 70°C, and features a 1/2-inch port size (PT1/2) with an effective cross-sectional area of up to 50.0 mm² (Cv=2.79) for efficient airflow. Key advantages include its maintenance-free operation (no lubrication required), the memory function in double air control models, and the ability to be integrated into a manifold base to save installation space.
Order Codes:
| Type |
Port Size |
Positions |
Valve Type |
| 4A430C-15 |
1/2" |
5/3 way |
Double Air Control Closed Center |
| 4A430E-15 |
1/2" |
5/3 way |
Double Air Control Exhaust Center |
| 4A430P-15 |
1/2" |
5/3 way |
Double Air Control Pressure Center |
Specification:
| Model |
4A430C-15 |
4A430E-15 |
4A430P-15 |
| Fluid |
Air(to be filtered by 40μm filter element) |
| Acting |
Exterior control |
| Port size [Note1] |
In=Out=Exhaust=1/2" |
Orifice size(Cv)
[Note4] |
4A410-15,4A420-15:48.0mm²(Cv=2.82)
4A430C-15:40.0mm²(Cv=2.35) |
| Valve type |
5 port 3 position |
| Operating pressure |
0.15~0.8MPa(21~114psi) |
| Proof pressure |
1.2MPa(175psi) |
| Temperature |
-20~70 °C |
| Material of body |
Aluminum alloy |
| Lubrication [Note2] |
Not required |
| Max. frequency [Note3] |
3 cycle/sec |
| Weight (g) |
735 |
[Note1] PT thread, G thread and NPT thread are available.
[Note2] Once lubricated air is used, continue with same medium to optimise valve life span. Lubricants like ISO VG32 or equivalent are recommended.
[Note3] The maximum actuation frequency is in the no-load state.
[Note4] Equivalent orifice S and Cv are all calculated from the flow rate data.
Flow Chart:
Structure:
Dimensions:
Quality Standards:
The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.
Samples:
You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.
After-sale service:
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
