Name: Taiwan Single Gear Oil Pump HYDROMAX HGP-3AF6R HGP-3AF25R HGP-3AF33R
Brand: FLY AUTOMATION
SKU: HGP-3AF6R HGP-3AF14R HGP-3AF25R HGP-3AF35R HGP-3AF8R HGP-3AF17R HGP-3AF28R HGP-3AF11R HGP-3AF19R HGP-3AF30R HGP-3AF13R HGP-3AF23R HGP-3AF33R
Price: 106.00 USD
Availability: InStock

Home Products Hydraulic System Components

Taiwan Single Gear Oil Pump HYDROMAX HGP-3AF6R HGP-3AF25R HGP-3AF33R

Product Details:

Place of Origin:	China Taiwan
Brand Name:	HYDROMAX
Model Number:	HGP-3AF6R HGP-3AF14R HGP-3AF25R HGP-3AF35R HGP-3AF8R HGP-3AF17R HGP-3AF28R HGP-3AF11R HGP-3AF19R HGP-3AF30R HGP-3AF13R HGP-3AF23R HGP-3AF33R

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	45-168USD
Packaging Details:	poly bags, box, cartons, pallets
Delivery Time:	3-12working days
Payment Terms:	T/T, Western Union, MoneyGram,Paypal
Supply Ability:	500 pcs per week

Contact Now

Detailed Product Description

Standard Pressure:	103.5 Bar (1500 PSI) AC 207 Bar (3000 PSI) DC	Body Material:	Carbon Steel
Shift Type:	Soft	Mounting Type:	Flange
Outlet Flow:	8-40L/min	Max. Pressure:	250 Kgf/cm2 ( 3500psi )
Displacement:	4-35 Cc/rev	Flange:	SAE 2-bolt, DIN 4-bolt, European 4-bolt
Highlight:	HYDROMAX Single Gear Oil Pump , HGP-3AF25R Single Gear Oil Pump , HGP-3AF6R Single Gear Oil Pump

Taiwan Single Gear Oil Pump HYDROMAX HGP-3AF6R HGP-3AF25R HGP-3AF33R

Displacement : 4-35 cc/rev
Max. Pressure : 250 kgf/cm2 ( 3500psi )
Flange : SAE 2-bolt, DIN 4-bolt, European 4-bolt
Ordering Code:
HGP-3AF6R
HGP-3AF14R
HGP-3AF25R
HGP-3AF35R
HGP-3AF8R
HGP-3AF17R
HGP-3AF28R
HGP-3AF11R
HGP-3AF19R
HGP-3AF30R
HGP-3AF13R
HGP-3AF23R
HGP-3AF33R

SPECIFICATIONS:

Model	Accurate Displacement Capacity ( cc/rev)	Operational Pressure ( kgf/cm')	Max. Pressure ( kgf/cm')	Speed (r.p.m.)			Weight (kg)
				Rate	Max.	Min.
HGP-3A-4	4	210 210	250 250	1800 1800	4000 4000	700 700	2.29
HGP-3A-6	6						2.37
HGP-3A-8	8.4	210	250	1800	3500	700	2.45
HGP-3A-11	11	210 210 210 210 210	250	1800	3000	600	2.60
HGP-3A-13	13 14.3 16.5		250 250 250	1800	3000 3000 3000	600 500 500 500	2.70 2.76
HGP-3A-14 HGP-3A-17				1800
				1800			2.87
HGP-3A-19	19.2		250	1800	3000		2.99
HGP-3A-23	23	210	250	1800	3000	500 500 500	3.19
HGP-3A-25	25 28	175 175	210 210	1800 1800	2800		3.24
HGP-3A-28					2500		3.35
HGP-3A-30 HGP-3A-33	30 33	175 140	210 175	1800	2500 2500	500 500 500	3.45
				1200			3.60
HGP-3A-35	35	125	140	1200	2500		3.71

Taiwan Single Gear Oil Pump HYDROMAX HGP-3AF6R HGP-3AF25R HGP-3AF33R
