Name: SMC ITV1011-022S/L/N ITV1031-022S/L/N ITV1051-022S/L/N Electro Pneumatic Regulator
Brand: Airwolf Automation
SKU: ITV1011-022S ITV1031-022S ITV1051-022S ITV1011-022L ITV1031-022L ITV1051-022L ITV1011-022N ITV1031-022N ITV1051-022N
Price: 100.00 USD
Availability: InStock

Home Products Pneumatic Solenoid Valves

SMC ITV1011-022S/L/N ITV1031-022S/L/N ITV1051-022S/L/N Electro Pneumatic Regulator

Product Details:

Place of Origin:	Japan, China
Brand Name:	SMC, AIRWOLF or OEM
Certification:	IP65
Model Number:	ITV1011-022S ITV1031-022S ITV1051-022S ITV1011-022L ITV1031-022L ITV1051-022L ITV1011-022N ITV1031-022N ITV1051-022N

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	80-120USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Item Code:	ITV1011-022S ITV1031-022S ITV1051-022S ITV1011-022L ITV1031-022L ITV1051-022L ITV1011-022N ITV1031-022N ITV1051-022N	Body Material:	Aluminum
Seals Material:	NBR	Operating Pressure:	0.1~1.0MPa
Working Temperature Range:	0~50°C (No Condensation)	Port Size:	1/4"
Function:	Proportional Pressure Control Via Electrical Signals	Operating Voltage:	12 To 15 VDC
Highlight:	electro pneumatic regulator SMC , pneumatic tube fittings ITV series , SMC ITV regulator with warranty

SMC ITV1011-022S/L/N ITV1031-022S/L/N ITV1051-022S/L/N Electro Pneumatic Regulator

The SMC ITV1000/2000/3000 Series Electro-Pneumatic Regulator delivers exceptional precision with linearity of ±0.5% or less of full scale, hysteresis under 0.5%, and repeatability within ±0.5%, ensuring highly accurate pressure control for demanding industrial processes. This precision is maintained across a wide pressure range from -80kPa to 0.9MPa, with the ability to handle both air pressure and vacuum applications while supporting multiple pressure units including MPa, kgf/cm², bar, PSI, and kPa for global compatibility.

Order Codes:

Item Code	Pressure range	Power supply voltage
ITV1011-022S	0.1 MPa	12 to 15 VDC
ITV1031-022S	0.5 MPa	12 to 15 VDC
ITV1051-022S	0.9 MPa	12 to 15 VDC
ITV1011-022L	0.1 MPa	12 to 15 VDC
ITV1031-022L	0.5 MPa	12 to 15 VDC
ITV1051-022L	0.9 MPa	12 to 15 VDC
ITV1011-022N	0.1 MPa	12 to 15 VDC
ITV1031-022N	0.5 MPa	12 to 15 VDC
ITV1051-022N	0.9 MPa	12 to 15 VDC

Specifications:

Model		ITV101□	ITV103□	ITV105□
		ITV201□	ITV203□	ITV205□
		ITV301□	ITV303□	ITV305□
Min. supply pressure		Set pressure + 0.1 MPa
Max. supply pressure		0.2 MPa	1.0 MPa
Set pressure range		0.005 to 0.1 MPa	0.005 to 0.5 MPa	0.005 to 0.9 MPa
Power supply	Voltage	24 VDC ±10%, 12 to 15 VDC
	Current consumption	Power supply voltage 24 VDC type: 0.12 A or less Power supply voltage 12 to 15 VDC type: 0.18 A or less

Input signal	Current type	4 to 20 mADC, 0 to 20 mADC (Sink type)
	Voltage type	0 to 5 VDC, 0 to 10 VDC
	Preset input	4 points (Negative common), 16 points (No common polarity)
	Digital input	10 bits (Parallel)
Input impedance	Current type	250 Ω or less
	Voltage type	Approx. 6.5 kΩ
	Preset input	Power supply voltage 24 VDC type: Approx. 4.7 kΩ Power supply voltage 12 VDC type: Approx. 2.0 kΩ

	Digital input	Approx. 4.7 kΩ
Output signal (Monitor output)	Analog output	1 to 5 VDC (Output impedance: Approx. 1 kΩ) 4 to 20 mADC (Sink type) (Output impedance: 250 Ω or less) Output accuracy ±6% F.S. or less


	Switch output	NPN open collector output: Max. 30 V, 80 mA PNP open collector output: Max. 80 mA

Linearity		±1% F.S. or less
Hysteresis		0.5% F.S. or less
Repeatability		±0.5% F.S. or less
Sensitivity		0.2% F.S. or less
Temperature characteristics		±0.12% F.S./°C or less
Output pressure display	Accuracy	±2% F.S. ±1 digit or less
	Min. unit	MPa: 0.001, kgf/cm²: 0.01, bar: 0.01, psi: 0.1, kPa: 1
Ambient and fluid temperatures		0 to 50°C (No condensation)
Enclosure		IP65
Weight	ITV10□□	Approx. 250 g (Without options)
	ITV20□□	Approx. 350 g (Without options)
	ITV30□□	Approx. 645 g (Without options)

Construction:

SMC ITV1011-022S/L/N ITV1031-022S/L/N ITV1051-022S/L/N Electro Pneumatic Regulator

Dimensions:

SMC ITV1011-022S/L/N ITV1031-022S/L/N ITV1051-022S/L/N Electro Pneumatic Regulator

Our Company:

Airwolf Automation is a world-renowned supply chain management company. A complete supply chain with 500,000 industrial parts can be supplied to 160 countries.

More than a thousand cooperative brands, super supply chain management ability, to ensure the fastest speed to meet your procurement needs.

Delivery:

1. If the products we have in store, we will send it out ASAP after payment.

2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.

3. Also we can send by your delivery acount if you want.

4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.

Q&A:

1. Q: Do you provide warranty for the goods?

A: Yes, we provide warranty for all the goods from us.

2. Q: Could seek best provide technology support?

A: We're in this field more than 10 years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.

3. Q: Does seek best keeps goods in stock or only trading?

A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.

4. Q:How about the terms of payment?

A:Generally through T/T and Paypal,Western Union also accept.
