Name: ITV1010-212S/L/N ITV1030-212S/L/N ITV1050-212S/L/N SMC Electro Pneumatic Regulator
Brand: Airwolf Automation
SKU: ITV1010-212S ITV1030-212S ITV1050-212S ITV1010-212L ITV1030-212L ITV1050-212L ITV1010-212N ITV1030-212N ITV1050-212N
Price: 100.00 USD
Availability: InStock

Home Products Pneumatic Solenoid Valves

ITV1010-212S/L/N ITV1030-212S/L/N ITV1050-212S/L/N SMC Electro Pneumatic Regulator

Product Details:

Place of Origin:	Japan, China
Brand Name:	SMC, AIRWOLF or OEM
Certification:	IP65
Model Number:	ITV1010-212S ITV1030-212S ITV1050-212S ITV1010-212L ITV1030-212L ITV1050-212L ITV1010-212N ITV1030-212N ITV1050-212N

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	80-120USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Item Code:	ITV1010-212S ITV1030-212S ITV1050-212S ITV1010-212L ITV1030-212L ITV1050-212L ITV1010-212N ITV1030-212N ITV1050-212N	Body Material:	Aluminum
Seals Material:	NBR	Operating Pressure:	0.1~1.0MPa
Working Temperature Range:	0~50°C (No Condensation)	Port Size:	1/4"
Function:	Proportional Pressure Control Via Electrical Signals	Operating Voltage:	24 VDC
Highlight:	SMC electro pneumatic regulator , pneumatic tube fittings regulator , ITV series electro pneumatic regulator

ITV1010-212S/L/N ITV1030-212S/L/N ITV1050-212S/L/N SMC Electro Pneumatic Regulator

The series offers advanced diagnostic and monitoring capabilities through multiple output signal options including analog 1-5VDC/4-20mA and switch outputs (NPN/PNP), with bright LED displays providing clear pressure visualization. Their modular design supports various mounting configurations including flat and L-brackets, while the IP65 equivalent enclosure ensures reliable operation in environments with dust and water exposure, making them suitable for cleanrooms, manufacturing floors, and outdoor industrial applications.

Order Codes:

Item Code	Pressure range	Power supply voltage
ITV1010-212S	0.1 MPa	24 VDC
ITV1030-212S	0.5 MPa	24 VDC
ITV1050-212S	0.9 MPa	24 VDC
ITV1010-212L	0.1 MPa	24 VDC
ITV1030-212L	0.5 MPa	24 VDC
ITV1050-212L	0.9 MPa	24 VDC
ITV1010-212N	0.1 MPa	24 VDC
ITV1030-212N	0.5 MPa	24 VDC
ITV1050-212N	0.9 MPa	24 VDC

Specifications:

Model		ITV101□	ITV103□	ITV105□
		ITV201□	ITV203□	ITV205□
		ITV301□	ITV303□	ITV305□
Min. supply pressure		Set pressure + 0.1 MPa
Max. supply pressure		0.2 MPa	1.0 MPa
Set pressure range		0.005 to 0.1 MPa	0.005 to 0.5 MPa	0.005 to 0.9 MPa
Power supply	Voltage	24 VDC ±10%, 12 to 15 VDC
	Current consumption	Power supply voltage 24 VDC type: 0.12 A or less Power supply voltage 12 to 15 VDC type: 0.18 A or less

Input signal	Current type	4 to 20 mADC, 0 to 20 mADC (Sink type)
	Voltage type	0 to 5 VDC, 0 to 10 VDC
	Preset input	4 points (Negative common), 16 points (No common polarity)
	Digital input	10 bits (Parallel)
Input impedance	Current type	250 Ω or less
	Voltage type	Approx. 6.5 kΩ
	Preset input	Power supply voltage 24 VDC type: Approx. 4.7 kΩ Power supply voltage 12 VDC type: Approx. 2.0 kΩ

	Digital input	Approx. 4.7 kΩ
Output signal (Monitor output)	Analog output	1 to 5 VDC (Output impedance: Approx. 1 kΩ) 4 to 20 mADC (Sink type) (Output impedance: 250 Ω or less) Output accuracy ±6% F.S. or less


	Switch output	NPN open collector output: Max. 30 V, 80 mA PNP open collector output: Max. 80 mA

Linearity		±1% F.S. or less
Hysteresis		0.5% F.S. or less
Repeatability		±0.5% F.S. or less
Sensitivity		0.2% F.S. or less
Temperature characteristics		±0.12% F.S./°C or less
Output pressure display	Accuracy	±2% F.S. ±1 digit or less
	Min. unit	MPa: 0.001, kgf/cm²: 0.01, bar: 0.01, psi: 0.1, kPa: 1
Ambient and fluid temperatures		0 to 50°C (No condensation)
Enclosure		IP65
Weight	ITV10□□	Approx. 250 g (Without options)
	ITV20□□	Approx. 350 g (Without options)
	ITV30□□	Approx. 645 g (Without options)

Construction:

ITV1010-212S/L/N ITV1030-212S/L/N ITV1050-212S/L/N SMC Electro Pneumatic Regulator

Dimensions:

ITV1010-212S/L/N ITV1030-212S/L/N ITV1050-212S/L/N SMC Electro Pneumatic Regulator
