Name: ITV1010-12N2S/L/N ITV1030-12N2S/L/N ITV1050-12N2S/L/N SMC Electro Pneumatic Regulator
Brand: Airwolf Automation
SKU: ITV1010-12N2S ITV1030-12N2S ITV1050-12N2S ITV1010-12N2L ITV1030-12N2L ITV1050-12N2L ITV1010-12N2N ITV1030-12N2N ITV1050-12N2N
Price: 100.00 USD
Availability: InStock

Home Products Pneumatic Solenoid Valves

ITV1010-12N2S/L/N ITV1030-12N2S/L/N ITV1050-12N2S/L/N SMC Electro Pneumatic Regulator

Product Details:

Place of Origin:	Japan, China
Brand Name:	SMC, AIRWOLF or OEM
Certification:	IP65
Model Number:	ITV1010-12N2S ITV1030-12N2S ITV1050-12N2S ITV1010-12N2L ITV1030-12N2L ITV1050-12N2L ITV1010-12N2N ITV1030-12N2N ITV1050-12N2N

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	80-120USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Item Code:	ITV1010-12N2S ITV1030-12N2S ITV1050-12N2S ITV1010-12N2L ITV1030-12N2L ITV1050-12N2L ITV1010-12N2N ITV1030-12N2N ITV1050-12N2N	Body Material:	Aluminum
Seals Material:	NBR	Operating Pressure:	0.1~1.0MPa
Working Temperature Range:	0~50°C (No Condensation)	Port Size:	1/4"
Function:	Proportional Pressure Control Via Electrical Signals	Operating Voltage:	24 VDC
Highlight:	SMC electro pneumatic regulator , ITV series pneumatic regulator , 12N2S/L/N pneumatic tube fitting

ITV1010-12N2S/L/N ITV1030-12N2S/L/N ITV1050-12N2S/L/N SMC Electro Pneumatic Regulator

A distinctive feature of the ITV series is its advanced communication capabilities, supporting multiple fieldbus protocols including CC-Link, DeviceNet, PROFIBUS DP, RS-232C, and IO-Link for seamless integration into smart factory environments. The EtherNet/IP version incorporates a second-generation chipset with enhanced diagnostics, web interface functionality, and the ability to daisy-chain multiple units while maintaining pressure setpoints during network interruptions. These regulators also feature grease-free specifications, modular mounting options, and adaptive control algorithms that ensure stable pressure output even with varying downstream air consumption.

Order Codes:

Item Code	Pressure range	Power supply voltage
ITV1010-12N2S	0.1 MPa	24 VDC
ITV1030-12N2S	0.5 MPa	24 VDC
ITV1050-12N2S	0.9 MPa	24 VDC
ITV1010-12N2L	0.1 MPa	24 VDC
ITV1030-12N2L	0.5 MPa	24 VDC
ITV1050-12N2L	0.9 MPa	24 VDC
ITV1010-12N2N	0.1 MPa	24 VDC
ITV1030-12N2N	0.5 MPa	24 VDC
ITV1050-12N2N	0.9 MPa	24 VDC

Specifications:

Model		ITV101□	ITV103□	ITV105□
		ITV201□	ITV203□	ITV205□
		ITV301□	ITV303□	ITV305□
Min. supply pressure		Set pressure + 0.1 MPa
Max. supply pressure		0.2 MPa	1.0 MPa
Set pressure range		0.005 to 0.1 MPa	0.005 to 0.5 MPa	0.005 to 0.9 MPa
Power supply	Voltage	24 VDC ±10%, 12 to 15 VDC
	Current consumption	Power supply voltage 24 VDC type: 0.12 A or less Power supply voltage 12 to 15 VDC type: 0.18 A or less

Input signal	Current type	4 to 20 mADC, 0 to 20 mADC (Sink type)
	Voltage type	0 to 5 VDC, 0 to 10 VDC
	Preset input	4 points (Negative common), 16 points (No common polarity)
	Digital input	10 bits (Parallel)
Input impedance	Current type	250 Ω or less
	Voltage type	Approx. 6.5 kΩ
	Preset input	Power supply voltage 24 VDC type: Approx. 4.7 kΩ Power supply voltage 12 VDC type: Approx. 2.0 kΩ

	Digital input	Approx. 4.7 kΩ
Output signal (Monitor output)	Analog output	1 to 5 VDC (Output impedance: Approx. 1 kΩ) 4 to 20 mADC (Sink type) (Output impedance: 250 Ω or less) Output accuracy ±6% F.S. or less


	Switch output	NPN open collector output: Max. 30 V, 80 mA PNP open collector output: Max. 80 mA

Linearity		±1% F.S. or less
Hysteresis		0.5% F.S. or less
Repeatability		±0.5% F.S. or less
Sensitivity		0.2% F.S. or less
Temperature characteristics		±0.12% F.S./°C or less
Output pressure display	Accuracy	±2% F.S. ±1 digit or less
	Min. unit	MPa: 0.001, kgf/cm²: 0.01, bar: 0.01, psi: 0.1, kPa: 1
Ambient and fluid temperatures		0 to 50°C (No condensation)
Enclosure		IP65
Weight	ITV10□□	Approx. 250 g (Without options)
	ITV20□□	Approx. 350 g (Without options)
	ITV30□□	Approx. 645 g (Without options)

Construction:

ITV1010-12N2S/L/N ITV1030-12N2S/L/N ITV1050-12N2S/L/N SMC Electro Pneumatic Regulator

Dimensions:

ITV1010-12N2S/L/N ITV1030-12N2S/L/N ITV1050-12N2S/L/N SMC Electro Pneumatic Regulator

Quality Standards:

The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.

Samples:

You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.

After-sale serivce:

We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.

Competitive Advantage:

Our product features:	Our Services Guarantee:
1) Competitive price	1) Prompt respond (Reply with 24 hours)
2) Good quality	2) Free Samples (Customer pay for the delivery cost)
3) Professional Packaging	4) 1 year warranty
4) Produce according to Customers’ instruction	5) Photos/videos are available during production.
5) None delay shipment	6) Loading inspection, and send loading photos before shipment.
