Festo Variable Stroke ADVU-32-...-P-A,-40,-50,-63 -S2 -S6 Double-Acting Compact Cylinder

Product Details:

Place of Origin:	Germany, China
Brand Name:	Festo, AIRWOLF or OEM
Certification:	CE, ISO9001
Model Number:	ADVU-32-...-P-A, ADVU-32-...-A-P-A, ADVU-32-...-P-A-S2, ADVU-32-...-A-P-A-S2, ADVU-32-...-P-A-S6, ADVU-32-...-A-P-A-S6, ADVU-40-...-P-A, ADVU-40-...-A-P-A, ADVU-40-...-P-A-S2, ADVU-40-...-A-P-A-S2, ADVU-40-...-P-A-S6, ADVU-40-...-A-P-A-S6,ADVU-50-...-P-A,

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	17-52USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Item Code:	ADVU-32-...-P-A, ADVU-32-...-A-P-A, ADVU-32-...-P-A-S2, ADVU-32-...-A-P-A-S2, ADVU-32-...-P-A-S6, ADVU-32-...-A-P-A-S6, ADVU-40-...-P-A, ADVU-40-...-A-P-A, ADVU-40-...-P-A-S2, ADVU-40-...-A-P-A-S2, ADVU-40-...-P-A-S6, ADVU-40-...-A-P-A-S6,ADVU-50-...-P-A,	Body Material:	Wrought Aluminium Alloy
Piston Rod Material:	High-alloy Stainless Steel(32mm), High-alloy Steel(40-63mm)	Seals Material:	Basic Version: PU, -S6: FKM
Working Pressure:	0.05~1MPa	Ambient Temperature:	Basic Version: -20°C~80°C, -S6: 0~120°C
Bore Size:	32, 40, 50, 63mm	Working Medium:	Compressed Air To ISO 8573-1:2010 [7:4:4]
Highlight:	Festo double-acting compact cylinder , Pneumatic air cylinder variable stroke , Festo ADVU compact cylinder

Festo Variable Stroke ADVU-32-...-P-A,-40,-50,-63 -S2 -S6 Double-Acting Compact Cylinder

The Festo ADVU series represents a line of high-performance compact cylinders engineered for industrial automation where space optimization is critical. These double-acting pneumatic actuators are characterized by a significant reduction in installation space—up to 50% smaller compared to standard ISO 15552 cylinders—while maintaining robust performance. The series offers a wide range of bore sizes from 12 mm to 125 mm and customizable stroke lengths from 1 mm to 400 mm. Key features include elastic cushioning at both end positions for smooth operation, non-contact position sensing capability via a magnetic piston, and versatile mounting options. Constructed from durable materials like anodized aluminum alloy for the body and high-alloy steel for the piston rod, the ADVU cylinders operate effectively within a pressure range of 0.05 to 1.0 MPa and can withstand ambient temperatures from -20°C to +80°C, making them suitable for demanding applications in packaging, assembly, and material handling.

Order Codes:

Item Code	Piston (mm)	Stroke (mm)	Part no.	Type	Item Code	Piston (mm)	Stroke (mm)	Part no.	Type
ADVU-32-...-P-A	32	1 ... 300	156004	with female thread	ADVU-32-...-A-P-A	12	1 ... 300	156044	with male thread
ADVU-40-...-P-A	40	1 ... 300	156005	with female thread	ADVU-40-...-A-P-A	16	1 ... 300	156045	with male thread
ADVU-50-...-P-A	50	1 ... 300	156006	with female thread	ADVU-50-...-A-P-A	20	1 ... 300	156046	with male thread
ADVU-63-...-P-A	63	1 ... 300	156007	with female thread	ADVU-63-...-A-P-A	25	1 ... 300	156047	with male thread
ADVU-32-...-P-A-S2	12	1 ... 300	156014	with female thread, Through piston rod	ADVU-32-...-A-P-A-S2	12	1 ... 300	156054	with male thread, Through piston rod
ADVU-40-...-P-A-S2	16	1 ... 300	156015	with female thread, Through piston rod	ADVU-40-...-A-P-A-S2	16	1 ... 300	156055	with male thread, Through piston rod
ADVU-50-...-P-A-S2	20	1 ... 300	156016	with female thread, Through piston rod	ADVU-50-...-A-P-A-S2	20	1 ... 300	156056	with male thread, Through piston rod
ADVU-63-...-P-A-S2	25	1 ... 300	156017	with female thread, Through piston rod	ADVU-63-...-A-P-A-S2	25	1 ... 300	156057	with male thread, Through piston rod
ADVU-32-...-P-A-S6	12	1 ... 300	156034	with female thread, 120°C Heat-resistant	ADVU-32-...-A-P-A-S6	12	1 ... 300	156094	with male thread, 120°C Heat-resistant
ADVU-40-...-P-A-S6	16	1 ... 300	156035	with female thread, 120°C Heat-resistant	ADVU-40-...-A-P-A-S6	16	1 ... 300	156095	with male thread, 120°C Heat-resistant
ADVU-50-...-P-A-S6	20	1 ... 300	156036	with female thread, 120°C Heat-resistant	ADVU-50-...-A-P-A-S6	20	1 ... 300	156096	with male thread, 120°C Heat-resistant
ADVU-63-...-P-A-S6	25	1 ... 300	156037	with female thread, 120°C Heat-resistant	ADVU-63-...-A-P-A-S6	25	1 ... 300	156097	with male thread, 120°C Heat-resistant

Datasheet:

General technical data
PistonØ		12	16	20	25	32	40	50	63	80	100	125
Pneumatic connection		M5	M5	M5	M5	G1/8	G1/8	G1/8	G1/8	G1/8	G1/4	G1/4
Piston rod end	Female thread	M3	M4	M5	M5	M6	M6	M8	M8	M10	M12	M16
Piston rod end	Male thread	M6	M8	M10x1.25				M12x1.25		M16x1.5	M20x1.5	M27x2
Operating medium		Compressed air to ISO 8573-1:2010 [7:4:4]
Note on the operating/pilot medium		Lubricated operation possible (in which case lubricated operation will always be required)
Design		Piston
Design		Piston rod
Cushioning		Elastic cushioning rings/plates at both ends
Position sensing		Via proximity switch
Type of mounting		With through-hole										–
		With female thread
		With accessories
Mounting position		Any

Operating conditions
Piston Ø			12	16	20	25	32	40	50	63	80	100	125
Operating pressure	Piston rod at one end	[MPa]	0.12 ... 1		0.1 ... 1		0.08 ... 1			0.06 ... 1			0.05 ... 1
		[bar]	1.2 ... 10		1 ... 10		0.8 ... 10			0.6 ... 10			0.5 ... 10
		[psi]	17.4 ... 145		14.5 ... 145		11.6 ... 145			8.7 ... 145			7.3 … 145
	Through piston rod S2/S20	[MPa]	0.15 ... 1	0.13 ... 1	0.12 ... 1		0.1 ... 1			0.08 ... 1			—
		[bar]	1.5 ... 10	1.3 ... 10	1.2 ... 10		1 ... 10			0.8 ... 10			—
		[psi]	21.8 ... 145	18.9 ... 145	17.4 ... 145		14.5 ... 145			11.6 ... 145			—
Ambient temperature(1)		°C	–20 ... +80
CRC(2)		2

1) Note operating range of proximity switches
2) More information www.festo.com/x/topic/crc

Materials:

Compact cylinder
[1]	Cylinder barrel		Wrought aluminium alloy
[2]	Cover		Wrought aluminium alloy
[3]	Piston rod	Ø 12 ... 32	High-alloy stainless steel
[3]	Piston rod	Ø 40 ... 125	High-alloy steel
[4]	Flange screws	Ø 12 ... 16	High-alloy stainless steel
[4]	Flange screws	Ø 20 ... 125	Galvanised steel
[5]	Dynamic seals		Basic version: Polyurethane, S6: Fluoro rubber

Dimensions:

Quality Standards:

The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.

Samples:

You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.

After-sale service:

We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.

Competitive Advantage:

Our product features:	Our Services Guarantee:
1) Competitive price	1) Prompt respond (Reply with 24 hours)
2) Good quality	2) Free Samples (Customer pay for the delivery cost)
3) Professional Packaging	3) 1 year warranty
4) Produce according to Customers’ instruction	4) Photos/videos are available during production.
5) None delay shipment	5) Loading inspection, and send loading photos before shipment.
