CONVUM MYOUTOKU CV-25HS, CV-30HS, CV-10HSCK CV Series Vacuum Ejectors

Product Details:

Place of Origin:	Japan, China
Brand Name:	CONVUM, MYOUTOKU, AIRWOLF or OEM
Model Number:	CV-25HS, CV-30HS, CV-10HSCK

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	5-19USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Item Code:	CV-25HS, CV-30HS, CV-10HSCK	Type:	With Pressure Switch, Without Pressure Switch
Material:	Aluminum Alloy	Operating Pressure:	0.1~0.6MPa
Working Temperature Range:	0～60℃ Without Freezing	Working Medium:	Dry Compressed Air Filtered By 40μm
Highlight:	CV Series vacuum ejectors , Pneumatic air cylinder vacuum ejectors , CV-25HS vacuum ejectors with warranty

CONVUM MYOUTOKU CV-25HS, CV-30HS, CV-10HSCK CV Series Vacuum Ejectors

As a versatile and fundamental component in automation systems, the CONVUM CV Series Vacuum Ejector stands out for its simple design, ease of installation, and application flexibility. The device creates vacuum suction solely from a supply of compressed air, making it incredibly reliable with no electrical components and minimal maintenance requirements beyond ensuring clean, dry air. This makes it particularly valuable in harsh industrial environments. Commonly used for controlling suction cups that handle objects in automation systems, from glass and electronic components to plastic and sheet metal, the CV Series' effectiveness and durability have made CONVUM a benchmark name in the field of vacuum ejection technology.

Order Codes:

Model	Nozzle size(Φmm)	Compatible Silencer
CV-25HS	2.5	MS6-01
CV-30HS	3	MS6-01
CV-10HSCK	1	MSS-01

Symbol:

CONVUM MYOUTOKU CV-25HS, CV-30HS, CV-10HSCK CV Series Vacuum Ejectors

Specifications:

Description Model number	Unit	CV-10			CV-15			CV-20			CV-25
Description Model number	Unit	HS	LS	HR	HS	LS	HR	HS	LS	HR	HS	LS	HS
Nozzle size	mm	1.0			1.5			2.0			2.5
Fluid		Non-lubricated compressed air
Ambient temperature	°C	0~60(No Freezing)
Operating pressure range	MPa	0.1~0.6
Rated pressure	MPa	0.5		0.35	0.5		0.35	0.5		0.35	0.5
Maximum vacuum pressure	kPa	-92	-57	-91	-92	-57	-91	-92	-57	-91	-92	-57	-92
Suction flow	L/min(ANR)	27	36	25	63	95	54	110	155	88	160	250	225
Air consumption	L/min(ANR)	44		100			180			265			385

Switch Specifications:

Description Model number		Unit	CV-CK
Fluid			Air
Operating pressure range		kPa	-20～-53
Withstand pressure		MPa	0.5
Ambient temperature range		℃	0～60 (No freezing)
Ambient humidity range		%RH	35～85 (No condensation)
Switch type			Reed switch, normally opened (N.O)
Rated voltage		V	AC125, 250
Maximum load current	AC125	A	5
Maximum load current	AC250	A	3
Repeatability		kPa	±5.3
Hysteresis		kPa	4.0～13.3
Cable length		mm	100

Dimensions:

CONVUM MYOUTOKU CV-25HS, CV-30HS, CV-10HSCK CV Series Vacuum Ejectors

Quality Standards:

The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.

Samples:

You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.

After-sale service:

We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.

Competitive Advantage:

Our product features:	Our Services Guarantee:
1) Competitive price	1) Prompt respond (Reply with 24 hours)
2) Good quality	2) Free Samples (Customer pay for the delivery cost)
3) Professional Packaging	3) 1 year warranty
4) Produce according to Customers’ instruction	4) Photos/videos are available during production.
5) None delay shipment	5) Loading inspection, and send loading photos before shipment.
