4HV210-06/08(L), 4HV230-06/08(L), 4HV310-08/10/15(L) AIRTAC 4HV Series 4/2 way 4/3 way Hand Lever Valve 1/8", 1/4", 3/8", 1/2"

4HV210-06/08(L), 4HV230-06/08(L), 4HV310-08/10/15(L) AIRTAC 4HV Series 4/2 way 4/3 way Hand Lever Valve 1/8", 1/4", 3/8", 1/2"

The AIRTAC 4HV&4HVL Series are manual hand lever valves designed for precise directional control in pneumatic systems. These valves are characterized by their smooth rotary switching action, which provides excellent tactile feedback and accurate positioning. A key feature is their availability in both 4/2-way and 4/3-way configurations, with the 4/3-way models offering three distinct center position functions (closed, exhausted, or pressurized) to suit different control needs for double-acting actuators. They operate effectively within a pressure range of 0 to 1.0 MPa, can withstand a proof pressure of 1.5 MPa, and function reliably in a wide temperature range from -20°C to +70°C. The series includes multiple port sizes, from 1/8" to 3/4", with corresponding flow capacities (Cv values ranging from 0.78 to 5.27), and offers flexible panel or body mounting options for easy installation.

[Note1] PT thread, G thread and NPT thread are available.

The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.

You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.

We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
