| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | QH-QS-6-1/8 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD15-25 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100 pcs per week |
| Order No: | 153487 | Model: | QH-QS-6-1/8 |
|---|---|---|---|
| Brand: | FESTO | Pneumatic Connection, Port 2: | QS-6 |
| Product Weight: | 15 G | Sealing Principle: | Soft |
| High Light: | Ball Valve QH-QS-6-1/8,Pneumatic Manual Ball Valve,153487 Pneumatic Manual Valve |
||
About product
1.Design:Ball valve.
2.Type of mounting:Screw-in.
3.Valve function:2/2 double solenoid.
4.Actuation type:Manual.
5.Sealing principle:Soft.
6.Male thread/push-in connector.
7.Standard nominal flow rate 3400 ... 84000 l/min.
8.Temperature range –20 ... +180°C.
Technical Data
| Valve function | 2/2 double solenoid |
| Pneumatic connection, port 1 | R1/8 |
| Pneumatic connection, port 2 | QS-6 |
| Type of actuation | Manual |
| Type of mounting | Screw-in |
| Standard nominal flow rate | 560 l/min |
| Nominal size | 2.5 mm |
| Operating pressure | -0.1 MPa ... 1 MPa |
| Operating pressure | -1 bar ... 10 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Sealing principle | Soft |
| Design | Ball valve |
| Symbol | 00991458 |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 15 g |
| Note on materials | RoHS-compliant |
Product picture
Sectional view
