| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | FVS-3-1/8 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD100-120 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 4-5 weeks |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 500 pcs per month |
| Type: | FVS-3-1/8 | Brand: | FESTO |
|---|---|---|---|
| Part No: | 3876 | Valve Function: | 3/2-way, Closed, Monostable |
| Type Of Actuation: | Mechanical | Media Temperature: | -10°C-60°C |
About product
Small and compact for a wide range of pneumatic applications
Flexibility of the pneumatic working ports provides a practical solution to different requirements
Durable with proven piston slide and piston poppet valves
Sturdy thanks to metal or plastic housing and connecting thread or connector
Front panel mounting or mounting on bracket
Technical Data
| Valve function | 3/2-way, closed, monostable |
| Type of actuation | Mechanical |
| Standard nominal flow rate | 146 l/min |
| pneumatic working port | G1/8 |
| Design | Poppet seat |
| Type of reset | Mechanical spring |
| Nominal size | 3.5 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Flow direction | Non-reversible |
| Symbol | 00991119 |
| Pilot medium | Compressed air to ISO 8573-1:2010 [-:-:-] |
| Note on forced dynamization | Switching frequency min. 1/year |
| Operating medium | Compressed air to ISO 8573-1:2010 [-:-:-] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -10°C-60°C |
| Ambient temperature | -10°C-60°C |
| Product weight | 130 g |
| Type of mounting | With through-hole |
| Pneumatic connection, port 1 | G1/8 |
| Pneumatic connection, port 2 | G1/8 |
| Pneumatic connection, port 3 | G1/8 |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material housing | Aluminium Anodised |
There are many models . Please contact me!
