MP301-8606011 Dump Truck Control Valve With Mounting Hole Air Control

MP301-8606011 Dump Truck Control Valve With Mounting Hole Air Control

  • MP301-8606011 Dump Truck Control Valve With Mounting Hole Air Control
  • MP301-8606011 Dump Truck Control Valve With Mounting Hole Air Control
  • MP301-8606011 Dump Truck Control Valve With Mounting Hole Air Control
MP301-8606011 Dump Truck Control Valve With Mounting Hole Air Control
Product Details:
Place of Origin: China
Brand Name: FLY
Certification: CE
Model Number: MP301-8606010
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiation
Packaging Details: Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement
Delivery Time: within 1-30 working days after payment
Payment Terms: T/T , Western Union
Supply Ability: 1000 pcs
Contact Now
Detailed Product Description
Model: MP301-8606011 Material: Aluminum Alloy
Color: Silver Media: Air
Name: Hand Control Valve
High Light:

automatic control valve

,

manual valve actuator

MP301-8606011 Dump Truck Control Valve with Mounting Hole Air control



Description

1.Operating pressure(Bar): up to 12
2.Working temperature: -40℃-/+80℃
3.Automatically locked in stop and fall position
4.Working medium:Air
5.Power: Hydraulic
6.Material: Aluminum alloy
7.Nominal diameter(mm) 4
8.Weight: 0.6kg

9.With plastic cover and four mounting holes



Make sure that air tubes:
1.are not too close to sharp objects.

2.are clear from moving parts.
3.are clear from exhaust and compressor lines.
4.can not get kinked.
5.are not too long.



Assembly instruction
1.Mount washer plus self locking nut on the threaded ends.
2.Fit the O-ring in the extra section and shift the first section on thethreaded ends .
3.Fit the threaded ends into the main section and tigthen themwith a adjustable pipe wrench
4.Fit this screw with some hydraulic sealant in the end section .
5.Fit other sections in the same way
6.Remove internal hexagon screw M5 frommain section to open the P-line tothe extra section



Product Features:

1.Body Material: Aluminum alloy
2.Small Operating force
3.Working Pressure: 5-10 Bar

4.Ambient temperature: -30℃-80℃
5.Automatically locked in stop and fall position
6.Transposition clearly
7.Able to coordinate with the Pneumatic control valve
8.Seal Material: HNBR
9.Simple operation
10.Easy to install
11.Long service life



Specifications

Model No. MP301-8606011
Means of Transport Ocean,Land,Air
Packing Boxes, Cartons
Standard or Nonstand Standard
Working Pressure 0.5-12 Bar
Ambient temperature -55ºC-180ºC
Media Oil
Material Aluminium alloy
Seal Material HNBR


MP301-8606011 Dump Truck Control Valve With Mounting Hole Air Control



Samples

You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.



Products shopping guide

For example: you want to purchase a batch of cylinders but you don't know which type you are really want, so you can tell me all your requirement and I'll recommend to you.



After-sale service

We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.

Make sure that air tubes:
1.are not too close to sharp objects.

2.are clear from moving parts.
3.are clear from exhaust and compressor lines.
4.can not get kinked.
5.are not too long.
