FESTO Round Cylinder DSNU-32-130-P-A Pneumatic Air Cylinders 193992

FESTO Round Cylinder DSNU-32-130-P-A Pneumatic Air Cylinders 193992

  • FESTO Round Cylinder DSNU-32-130-P-A Pneumatic Air Cylinders 193992
  • FESTO Round Cylinder DSNU-32-130-P-A Pneumatic Air Cylinders 193992
  • FESTO Round Cylinder DSNU-32-130-P-A Pneumatic Air Cylinders 193992
FESTO Round Cylinder DSNU-32-130-P-A Pneumatic Air Cylinders 193992
Product Details:
Brand Name: FESTO
Model Number: DSNU-32-130-P-A
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 30-50
Packaging Details: Plastic bags,Boxes, Cartons
Delivery Time: 7-10 working days
Payment Terms: T/T , Western Union
Supply Ability: 1000 pcs
Contact Now
Detailed Product Description
Model Code: DSNU-32-130-P-A Part No: 193992
Brand: FESTO Piston Diameter: 32mm
Cushioning Length: 14mm Material Seals: NBR TPE-U(PU)
Highlight:

193992 Pneumatic Air Cylinders

,

Pneumatic FESTO Round Cylinder

,

193992 Pneumatic Air Cylinders

FESTO Round cylinder DSNU-32-130-P-A 193992 Pneumatic Air Cylinders



About Product

1.Good running performance and long service life.

2.Piston rod with male and female thread.

3.Extensive range of accessories makes it possible to install the cylinder virtually anywhere.

4.The basic versions conform to ISO 6432, variants are based on these standards.

5.Stainless steel piston rod.



Technical data

Stroke 130mm
Piston diameter 32mm
Mounting position optional
Design Piston Piston rod Cylinder barrel
Position detection Via proximity switch
Protection against torque/guide Square piston rod
Mode of operation Double-acting
Ambient temperature -20°C-120°C
Cushioning length 14 mm
Basic weight for 0 mm stroke 370.5 g
Additional weight per 10 mm stroke 15.5 g
Pneumatic connection G1/8
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy
Material seals NBR TPE-U(PU)
Material piston rod High-alloy stainless steel



General technical data



FESTO Round Cylinder DSNU-32-130-P-A Pneumatic Air Cylinders 193992

There are so many models,please contact with me.



Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.
