Place of Origin: | China |
Brand Name: | HYDAC |
Model Number: | 1253064,0160 D 005 BH4HC |
Minimum Order Quantity: | 1pc |
---|---|
Price: | EXW USD50-100 |
Packaging Details: | plastic bag, color box |
Delivery Time: | 5-7 working days |
Payment Terms: | T/T, Western Union, Paypal |
Supply Ability: | 600 pcs per month |
Product Description: | 0160 D 005 BH4HC | Part No: | 1253064 |
---|---|---|---|
Brand: | HYDAC | Element Type: | D |
Filterfeinheit: | 005 µm | Operating Temperature: | Up To 100°C |
High Light: | BH4HC Hydraulic System D Elements,D Type Hydraulic Filter Element,Hydraulic System Components 1253064 |
Product description: 0160 D 005 BH4HC
Part no.:: 1253064
Brand: HYDAC
Element Type:D
Filterfeinheit:005 µm
Operating temperature: up to 100°C
Compatible with all conventional operating media
Without bypass valve
Type "D" elements are used in pressure filters, e.g. in the series DF, DFF, DFG, DFP, DFZ, DFDK, LF, MDF.
Application
The filter element is an indispensable part of the pipeline series for conveying media. It is usually installed in the filter at the inlet end of the hydraulic system to filter out the metal particles, pollution impurities, etc. in the fluid medium, which can protect the normal operation of the equipment. When the fluid enters the filter, its impurities are blocked, and the clean filtrate is discharged from the filter outlet. When cleaning is needed, just take the filter element out of the filter, treat it with industrial liquid, and then put it in.
The hydraulic oil filter element itself has a self sealing valve, which will not cause oil backflow even during maintenance. Open a valve next to it. When the differential pressure reaches 0.35MPA due to impurity blockage, it will automatically open to make the system operate well.
Product details
Characteristic | Value / Characteristic / Information |
Breite [mm] | 185,00 |
By-pass | no by-pass |
Customer protection | without custom. protection |
Element material | Betamicron high press. |
Element Type | D |
Filterfeinheit | 5 µm |
Further characteristics elem. | no further details |
Höhe [mm] | 82,00 |
Länge [mm] | 82,00 |
sealing material | Perbunan |
Size | 0160 |
Advantage
Good performance, durable, complete models. |
Long service life. |
Acid and alkali resistance, corrosion resistance. |
High strength and wear resistance. |
High filtering accuracy and low friction coefficient. |
Good moisture resistance. |
Another model as follow
Part no | Product description |
1253066 | 0160 D 010 BH4HC |
1253090 | 0330 D 010 BH4HC |
1253042 | 0060 D 010 BH4HC |
1253098 | 0500 D 010 BH4HC |
