Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
Place of Origin: | China |
Brand Name: | OEM |
Certification: | CE |
Model Number: | MP301-8606010 |
Minimum Order Quantity: | 1 piece |
---|---|
Price: | Negotiation |
Packaging Details: | Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement |
Delivery Time: | within 1-30 working days after payment |
Payment Terms: | T/T , Western Union |
Supply Ability: | 1000 pcs |
Model: | MP301-8606010 | Material: | Aluminum Alloy |
---|---|---|---|
Color: | Silver | Media: | Air |
Name: | Hand Control Valve | ||
High Light: | automatic control valve,manual valve actuator |
MP301-8606010 Aluminum alloy Dump Truck Control Valve with Mounting Bracket
Product Features:
1.Body Material: Aluminum alloy
2.Small Operating force
3.Working Pressure: 5-10 Bar
4.Ambient temperature: -30℃-80℃
5.Automatically locked in stop and fall position
6.Transposition clearly
7.Able to coordinate with the Pneumatic control valve
8.Seal Material: HNBR
9.Simple operation
10.Easy to install
11.Long service life
Description
1.Operating pressure(Bar): up to 12
2.Working temperature: -40℃-/+80℃
3.Automatically locked in stop and fall position
4.Working medium:Air
5.Power: Hydraulic
6.Material: Aluminum alloy
7.Nominal diameter(mm) 4
8.Weight: 0.6kg
Assembly instruction
1.Mount washer plus self locking nut on the threaded ends.
2.Fit the O-ring in the extra section and shift the first section on thethreaded ends .
3.Fit the threaded ends into the main section and tigthen themwith a adjustable pipe wrench
4.Fit this screw with some hydraulic sealant in the end section .
5.Fit other sections in the same way
6.Remove internal hexagon screw M5 frommain section to open the P-line tothe extra section
Make sure that air tubes:
1.are not too close to sharp objects.
2.are clear from moving parts.
3.are clear from exhaust and compressor lines.
4.can not get kinked.
5.are not too long.
Specifications
Working medium | Air | |
Operating pressure (Bar) | up to 12 | |
Working temperature | Distributor valve | - 30 ºC / + 80 ºC |
Automatic fittings | - 20 ºC / + 80 ºC | |
Nominal diameter (mm) | 4 | |
Weight (Kg) | 0.6 |
Samples
You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.
Products shopping guide
For example: you want to purchase a batch of cylinders but you don't know which type you are really want, so you can tell me all your requirement and I'll recommend to you.
After-sale service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
