| Brand Name: | FESTO |
| Model Number: | ADVU-50-50-A-P-A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD50-70 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1000 pcs per month |
| Part No: | 156642 | Brand: | FESTO |
|---|---|---|---|
| Stroke: | 50mm | Type: | ADVU-50-50-A-P-A |
| Piston Diameter: | 50mm | Ambient Temperature: | -20°C-80°C |
| High Light: | ADVU-50-50-A-P-A,156642 Pneumatic Air Cylinders,Male Thread FESTO Compact Cylinder |
||
About product
Technical Data
| Stroke | 50 mm |
| Piston diameter | 50 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Mode of operation | Double-acting |
| Piston-rod end | Male thread |
| Design | Piston Piston rod |
| Position detection | Via proximity switch |
| Symbol | 00991217 |
| Variants | Piston rod at one end |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Basic weight for 0 mm stroke | 560 g |
| Additional weight per 10 mm stroke | 72 g |
| Type of mounting | Either: With through-hole With accessories |
| Pneumatic connection | G1/8 |
| Material collar screws | Galvanised steel |
| Material cover | Wrought aluminium alloy |
| Material dynamic seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy |
Dimensions – Basic cylinder
There are so many kinds. Please contact with me!
Contact Person: Jaren
Tel: 0086-15257858856
Fax: 86-152-57858856
