| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | SIEN-M8B-PS-S-L |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD50-60 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 500 pcs per month |
| Type: | SIEN-M8B-PS-S-L | Part No: | 150387 |
|---|---|---|---|
| Brand: | FESTO | Ambient Temperature: | -25°C-70°C |
| Weight: | 18 G | Type Of Mounting: | Via Lock Nut |
| High Light: | SIEN-M8B-PS-S-L,Pneumatic Festo Proximity Sensor,Via Lock Nut Proximity Sensor |
||
About product
1.For DC voltage.
2.Round design.
3.With standard switching.
4.3-wire cable, 2.5 m long.
5.Active surface.
Technical Data
| Conforms to standard | EN 60947-5-2 |
| Symbol | 00991701 |
| Approval | RCM trademark c UL us listed (OL) |
| CE mark (see declaration of conformity) | To EU EMC Directive |
| Note on materials | RoHS-compliant |
| Rated operating distance | 1.5 mm |
| Assured operating distance | 1.21 mm |
| Ambient temperature | -25°C-70°C |
| Switching output | PNP |
| Voltage drop | 2 V |
| Inductive protective circuit | Integrated |
| Short circuit current rating | Pulsed |
| No-load supply current | 10 mA |
| Reverse polarity protection | For all electrical connections |
| Size | M8x1 |
| Type of mounting | Via lock nut |
| Mounting type | Flush |
| Product weight | 18 g |
| Switching status indication | Yellow LED |
| Ambient temperature with moving cable | -5°C-70°C |
| Degree of protection | IP65 IP67 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Additional information for sensor selection | with standard sensing distance |
| Electrical output | PNP |
| Selection of sensor design | Standard |
Dimensions – M8
