| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Place of Origin: | CHINA |
| Brand Name: | SIEMENS |
| Model Number: | 6GK7443-1EX30-0XE0 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | EXW USD1960-2000 |
| Packaging Details: | carton |
| Delivery Time: | 8-15 work days |
| Payment Terms: | T/T, Western Union,Paypal |
| Supply Ability: | 100PCS Every month |
| Model: | CP 443-1 | Produktart: | Communications Processor |
|---|---|---|---|
| Controller Platform: | S7-400 | Packaging Dimension: | 23,30 X 30,20 X 3,80 |
| Net Weight (kg): | 0.9KG | Herstellungsland Und -region: | Deutschland |
| High Light: | S7-400 Siemens Communication Processor,CP 443-1 Communication Processor,6GK7443-1EX30-0XE0 Processor |
||
| Product | |||
| Article Number (Market Facing Number) | 6GK7443-1EX20-0XE0 | ||
| Product Description | ********** spare part ********* communications processor CP 443-1 for connection of SIMATIC S7-400 to industrial Ethernet over ISO, TCP/IP and UDP, S7 communication, fetch/write, SEND/RECEIVE with and without RFC1006 multicast, PROFINET IO controller, DHCP, SNMP V2, web, diagnostics, initialization via LAN, access protection via IP access list integrated real-time switch ERTEC 400, 2xRJ45 connection for LAN with 10/100 Mbit/s | ||
| Product family | Not available | ||
| Product Lifecycle (PLM) | PM410:Product cancellation | ||
| PLM Effective Date | Product is cancelled since: 01.10.2015 | ||
| Notes |
The product was replaced with the following successor product: 6GK7443-1EX30-0XE0
Sucessor:Compatible successor 6GK7443-1EX30-0XE0
This product is a Spare Part, please visit the Spares & Service section for more information
If you need assistance please contact our local Siemens office
|
||
| Successor information | |||
| Successor | 6GK7443-1EX30-0XE0 | ||
| Successor Description | Communications processor CP 443-1; 2x 10/100 Mbit/s (IE switch); RJ45 ports; ISO; TCP; UDP; PROFINET IO controller; S7 communication; Open communication (SEND/ RECEIVE); S7 routing; IP configuration via DHCP/ Block; IP Access control list; time-of-day synchronization; extended web diagnostics; Fast Startup; Support for PROFIenergy; | ||
| Price data | |||
| Region Specific PriceGroup / Headquarter Price Group | S50 / 5PC | ||
| List Price | Show prices | ||
| Customer Price | Show prices | ||
| Surcharge for Raw Materials | None | ||
| Metal Factor | None | ||
| Delivery information | |||
| Export Control Regulations | ECCN : 5A991X / AL : N | ||
| Standard lead time ex-works | 1 Day/Days | ||
| Net Weight (kg) | 0,821 Kg | ||
| Packaging Dimension | 23,30 x 30,20 x 3,80 | ||
| Package size unit of measure | CM | ||
| Quantity Unit | 1 Piece | ||
| Packaging Quantity | 1 | ||
| Additional Product Information | |||
| EAN | 4019169121705 | ||
| UPC | Not available | ||
| Commodity Code | 85176200 | ||
| LKZ_FDB/ CatalogID | IK-E | ||
| Product Group | X0AI | ||
| Group Code | R322 | ||
| Country of origin | Germany | ||
| Compliance with the substance restrictions according to RoHS directive | Since: 09.11.2007 | ||
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. | ||
| WEEE (2012/19/EU) Take-Back Obligation | Yes | ||
| REACH Art. 33 Duty to inform according to the current list of candidates |
|
||
| Classifications | |||
| Not available | |||
