SIEMENS Simatic MP277 10" Touch Multi Panel 6AV6643-0CD01-1AX1

Product Details:

Place of Origin:	CHINA
Brand Name:	SIEMENS
Model Number:	6AV6643-0CD01-1AX1

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	EXW USD2307-2350
Packaging Details:	carton
Delivery Time:	15-30 work days
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	100PCS Every month

Contact Now

Detailed Product Description

Screen Diagonal:

10.4in

Resolution (WxH In Pixel):

640 X 480

MTBF Backlighting (at 25 °C):

50000h

Weight:

2.5KG

Highlight:

Multi Panel 6AV6643-0CD01-1AX1

MP277 Simatic Touch Multi Panel

10" Simatic Multi Panel

SIEMENS Simatic MP277 10" Touch 6AV6643-0CD01-1AX1

Name: SIEMENS Simatic MP277 10" Touch Multi Panel 6AV6643-0CD01-1AX1
Brand: FLY AUTOMATION
SKU: 6AV6643-0CD01-1AX1
Price: 2,328.00 USD
Availability: InStock

SIEMENS Simatic MP277 10" Touch Multi Panel 6AV6643-0CD01-1AX1

Description:

Siemens 6AV6 643-0CD01-1AX1 SIMATIC MP 277 Multi Panel with retentive memory, Operator Interface Terminal, 10.4-inch, Color, Touchscreen, ARM CPU, 6MB Configuring Memory, 1 x 12 Mbit/s RS-422/485 Interface Port (MPI/DP/PPI), 1 x 10/100 Mbit/s RJ-45 Ethernet Port (IE/PN), 1 x SD/Multi Media Card Slot, 2 x USB Ports, 640x480 TFT LCD with 65K Colors, Windows CE Operating System, configurable with WinCC Flexible Standard 2005 SP1 and higher, 24V DC Power.

Manufacturer	Siemens
Product No.	6AV6643-0CD01-1AX1
Product type	SIMATIC MP277 10" Touch Multi Panel
Customer-specific configuration	Yes
Design of display	TFT
Screen diagonal	10.4in
Color type	Colors
Horizontal image resolution	640Pixel
Vertical image resolution : 480Pixel	480Pixel
Resolution (WxH in pixel)	640 x 480
MTBF backlighting (at 25 °C)	50000h
Control elements	Touch screen
Keys with LED	No
System keys	No
Numeric/alphabetical input	Yes / Yes
Mounting position	vertical
Type of supply voltage	DC
Processor type	ARM
Type of memory	Flash / RAM
Capacity of main memory, max.	128Mbyte
Clock Type	Hardware clock, battery backup, synchronizable
Interfaces/bus type	1 x RS422, 1 x RS485, 1 x Ethernet (RJ45)
Weight	2.65 Kg
Shipping Weight	8 Kg
