QSF-1/8-8-B Pneumatic Tube Fittings Push In Fitting 153025 4052568011000

Product Details:

Place of Origin:	China
Brand Name:	FESTO
Model Number:	QSF-1/8-8-B

Payment & Shipping Terms:

Minimum Order Quantity:	10 PCS
Price:	EXW USD2-5
Packaging Details:	carton，OPP bag
Delivery Time:	5-7 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	600 pcs per week

Contact Now

Detailed Product Description

Nominal Size:	7 Mm	Order No:	153025
Brand:	FESTO	GTIN:	4052568011000
Specifications:	QSF-1/8-8-B	Weight:	16g
Highlight:	Pneumatic Tube Push In Fitting , 153025 Pneumatic Tube Fittings , 7 mm Pneumatic Tube Fittings

FESTO,Push-in fitting,QSF-1/8-8-B,153025,GTIN: 4052568011000,Pneumatic Tube Fittings

Name: QSF-1/8-8-B Pneumatic Tube Fittings Push In Fitting 153025 4052568011000
Brand: FLY AUTOMATION
SKU: QSF-1/8-8-B
Price: 3.00 USD
Availability: InStock

Nominal size:7 mm

Order no:153025

Brand:FESTO

GTIN:4052568011000

Specifications:QSF-1/8-8-B

Weight:16g

Product Technical Data

Size	Standard
Nominal size	7mm
Mounting position	optional
Size of pack	10
Design	Push-pull principle
Note on operating and pilot medium	Lubricated operation possible
Corrosion resistance class CRC	1 - Low corrosion stress
Product weight	16 g
Pneumatic connection, port 1	Female thread G1/8
Pneumatic connection, port 2	For tubing outside diameter of 8 mm
Colour of release ring	Blue
Material housing	PBT
Material release ring	POM
Material tubing seal	NBR
Material tubing clamp component	High-alloy stainless steel
Type of seal on screw-in stud	Coating

Another Specifications

Specifications	Order NO	GTIN	Nominal size(mm)	Weight(g)	EXW Price
QSF-1/8-4-B	153022	4052568031268	3	13	USD2-5
QSF-1/8-6-B	153023	4052568031275	5	15	USD2-5
QSF-1/8-8-B	153025	4052568011000	7	16	USD2-5
QSF-1/4-4-B	190650	4052568042851	3	21	USD2-5
QSF-1/4-6-B	153024	4052568031282	5	23	USD2-5
QSF-1/4-8-B	153026	4052568031299	7	24	USD2-5
QSF-1/4-10-B	153028	4052568031312	9	30	USD2-5
QSF-1/4-12-B	190651	4052568042868	11	44	USD2-5
QSF-3/8-6-B	190652	4052568042875	5	30	USD2-5
QSF-3/8-8-B	153027	4052568031305	7	32	USD2-5
QSF-3/8-10-B	153029	4052568031329	9	38	USD2-5
QSF-3/8-12-B	153030	4052568031336	11	46	USD2-5
QSF-1/2-12-B	190653	4052568014841	11	56	USD2-5

Fitting/removing the tubing

Fitting

The prerequisite for ensuring that the inside seal is securely held and protected

against damage is that the tube is cut into straight lengths and deburred.

1) Insert tubing as far as the stop.

It is important to ensure that the tubing is inserted into the inner seal. De

pending on the tolerance between the tubing and the seal, the contact of the

tubing with the seal may be wrongly interpreted as the stop.

2) Check that the tubing connection is secure by pulling gently on the tube.

Removal

1) The tubing can be detached easily by pressing and holding down the release

ring. Carefully remove the tubing from the fitting.

2) Before re-using the tubing, remove the damaged part by cutting it of.

Characteristic

1.Simply "plug and work"

The stainless steel retaining claw holds the tubing securely without damaging its surface. Vibration and pressure surges are absorbed.

2.Reliably connected

A nitrile rubber sealing ring guarantees a perfect seal between standard OD tubing and the body of the fitting.The standard tubing combined with the Festo push-in connector is suitable for compressed air and vacuum.

3.The captive seal

All brass parts of Festo's push-in fittings have nickel-plated surfaces and are thus highly resistant to corrosion.The tapered ISO R threads have a self-sealing PTFE coating, which allows the fitting to be re-used up to five times without the need for additional sealing components.

4.Rotatable

It can be rotated once it has been fitted.

Push-in fitting QSF

Female thread with external hex

There are many specifications of connectors, price and delivery time. Welcome to inquire.
