| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | DSNU-40-125-P-A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD60-80 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100 pcs per month |
| Part No: | 195995 | Type: | DSNU-40-125-P-A |
|---|---|---|---|
| Brand: | FESTO | Piston Diameter: | 40 Mm |
| Stroke: | 125 Mm | Symbol: | '00991217 |
| High Light: | Pneumatic Festo Round Cylinder,195995 Festo Round Cylinder,Round Pneumatic Air Cylinders |
||
About product
1.Good running performance and long service life.
2.Self-adjusting pneumatic end-position cushioning saves time during commissioning and adapts optimally to load and speed changes.
3.Wide range of variants for customised applications.
Technical Data
| Stroke | 125 mm |
| Piston diameter | 40 mm |
| Piston rod thread | M12x1.25 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Design | Piston Piston rod Cylinder barrel |
| Position detection | Via proximity switch |
| Symbol | 00991217 |
| Operating pressure | 0.1 MPa ... 1 MPa |
| Operating pressure | 1 bar ... 10 bar |
| Mode of operation | Double-acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 961 g |
| Type of mounting | With accessories |
| Pneumatic connection | G1/4 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | High-alloy stainless steel |
Product picture
There are so many type ,please call me immediately!
Contact Person: Jaren
Tel: 0086-15257858856
Fax: 86-152-57858856
