Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051

Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051

  • Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
  • Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
  • Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: ADNGF-20-60-P-A
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD40-50
Packaging Details: plastic bag, carton,OPP bag
Delivery Time: 10-15working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 50 pcs per month
Contact Now
Detailed Product Description
Brand: FESTO Type: ADNGF-20-60-P-A
Part No: 554228 GTIN: 4052568006051
Piston Diameter: 20 Mm Stroke: 60 Mm
High Light:

60mm Stroke Pneumatic Air Cylinders

,

FESTO Compact Cylinder 554228

,

Aluminium Anodised Compact Pneumatic Cylinder

FESTO Compact cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051 Pneumatic Air Cylinders

About product

Cushioning types Cushioning P
Mode of operation The drive has elastic polymer flexible end-position cushioning
Application Small loads
Low speeds
Small cushioning capacity
Advantages No adjustment required
Time-saving



Technical Data

Stroke 60 mm
Piston diameter 20 mm
Based on standard ISO 21287
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Design Piston Piston rod Profile barrel
Position detection Via proximity switch
Protection against torque/guide Guide rod with yoke
Mode of operation Double-acting
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20°C-80°C
Basic weight for 0 mm stroke 161 g
Additional weight per 10 mm stroke 26 g
Pneumatic connection M5
Note on materials RoHS-compliant
Material cover Aluminium Anodised
Material seals TPE-U(PUR)
Material piston rod High-alloy steel
Material cylinder barrel Wrought aluminium alloy Smooth anodised



Other size as below

Type Order no Weight(g) Price
ADNGF-20-5-P-A 554220 174 USD40-50
ADNGF-20-10-P-A 554221 187 USD40-50
ADNGF-20-15-P-A 554222 200 USD40-50
ADNGF-20-20-P-A 554223 213 USD40-50
ADNGF-20-25-P-A 554224 226 USD40-50
ADNGF-20-30-P-A 554225 239 USD40-50
ADNGF-20-40-P-A 554226 265 USD40-50
ADNGF-20-50-P-A 554227 291 USD40-50
ADNGF-20-60-P-A 554228 317 USD40-50

FESTO, the world's leading automation technology supplier, is committed to promoting the development of industrial automation with intelligent and convenient solutions. FESTO works with you to improve productivity.



A wide range of products with excellent prices. Please hurry to me!
