MVH-5-1/8-B Monostable Pneumatic Solenoid Valves 19779 GTIN4052568113476

Product Details:

Place of Origin:	China
Brand Name:	FESTO
Model Number:	MVH-5-1/8-B

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	EXW USD80-100
Packaging Details:	Plastic bag, Carton
Delivery Time:	7-10 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	100 pcs per month

Contact Now

Detailed Product Description

Order No:	19779	Brand:	FESTO
Model:	MVH-5-1/8-B	Product Weight:	230 G
Material Housing:	Die-cast Aluminium	Valve Function:	5/2-way, Monostable
Highlight:	MVH-5-1/8-B Pneumatic Solenoid Valves , Die Cast Aluminium Air Solenoid Valve , Monostable Pneumatic Solenoid Valves

FESTO Solenoid valve MVH-5-1/8-B 19779 GTIN4052568113476 Pneumatic Solenoid Valves

Name: MVH-5-1/8-B Monostable Pneumatic Solenoid Valves 19779 GTIN4052568113476
Brand: FLY AUTOMATION
SKU: MVH-5-1/8-B
Price: 90.00 USD
Availability: InStock

About product

1.electrical actuation.

2.Functional and timeless design, enclosed front housing.

3.Poppet valve for monostable functions or piston spool for more complex versions with air spring.

Technical Data

Valve function	5/2-way, monostable
Type of actuation	Electric
Construction width	26 mm
Standard nominal flow rate	750 l/min
pneumatic working port	G1/8
Operating voltage	24V DC
Design	Poppet seat
Type of reset	Mechanical spring
Nominal size	5 mm
Sealing principle	Soft
Mounting position	optional
Manual override	Non-detenting
Type of piloting	Pilot actuated
Pilot air supply	Internal
Flow direction	Non-reversible
Symbol	00991035
lap	Underlap
b value	0.34
C value	3 l/sbar
Max. switching frequency	3 Hz
Switching time off	36 ms
Switching time on	20 ms
Characteristic coil data	24 V DC: 2.5 W
Permissible voltage fluctuations	+/- 10 %
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Storage temperature	-40°C-60°C
Media temperature	-5°C-50°C
Ambient temperature	-5°C-50°C
Product weight	230 g
Type of mounting	On PR rail With through-hole Either:
Pilot exhaust port 84	M5
Pneumatic connection, port 1	G1/8
Pneumatic connection, port 2	G1/8
Pneumatic connection, port 3	G1/8
Pneumatic connection, port 4	G1/8
Pneumatic connection, port 5	G1/8
Note on materials	RoHS-compliant
Material seals	NBR TPE-U(PU)
Material housing	Die-cast aluminium

Another Size as below,

Type	Order no	Price
MVH-5-1/8-L-B	19749	USD80-100
MVH-5-1/4-L-B	31009	USD80-100
MVH-5-3/8-L-B	14947	USD80-100
MVH-5-1/8-L-S-B	19750	USD80-100
MVH-5-1/4-L-S-B	33184	USD80-100
MVH-5-3/8-L-S-B	33180	USD80-100
MVH-5-1/8-B	19779	USD80-100
MVH-5-1/4-B	15701	USD80-100
MVH-5-3/8-B	19945	USD80-100
MVH-5-1/8-S-B	30996	USD80-100
MVH-5-1/4-S-B	15903	USD80-100
MVH-5-3/8-S-B	15342	USD80-100
