Mini Slide Pneumatic Air Cylinders DGST-8-30-E1A 8078835 GTIN4052568446666

Mini Slide Pneumatic Air Cylinders DGST-8-30-E1A 8078835 GTIN4052568446666

  • Mini Slide Pneumatic Air Cylinders DGST-8-30-E1A 8078835 GTIN4052568446666
  • Mini Slide Pneumatic Air Cylinders DGST-8-30-E1A 8078835 GTIN4052568446666
Mini Slide Pneumatic Air Cylinders DGST-8-30-E1A 8078835 GTIN4052568446666
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: DGST-8-30-E1A
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD300-350
Packaging Details: Plastic bag, Carton
Delivery Time: 10-15working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 20 pcs per month
Contact Now
Detailed Product Description
Type: DGST-8-30-E1A Part No: 8078835
Brand: FESTO GTIN: 4052568446666
Symbol: '00991249 Max. Speed: 0.5 M/s
Highlight:

30mm Double Acting Pneumatic Cylinder

,

0.5m/s Pneumatic Air Cylinders

,

Mini Slide Pneumatic Compact Air Cylinder

FESTO Mini slide DGST-8-30-E1A 8078835 GTIN4052568446666 Pneumatic Air Cylinders

About Product

1.Powerful twin-piston drive.

2.Shortest mini slide on the market.

3.Precise recirculating ball bearing guide.

4.Compact mini slide.

5.Slide and yoke plate as a single component.



Technical Data

Stroke 30 mm
Piston diameter 8 mm
Operating mode, drive unit Yoke
Cushioning Elastomer cushioning, double-sided, stroke not adjustable
Mounting position optional
Guide Recirculating ball bearing guide
Design Twin piston Yoke Piston rod Slide
Position detection Via proximity switch
Symbol 00991249
Max. speed 0.5 m/s
Repetition accuracy <= 0.3 mm
Mode of operation Double-acting
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -10°C-60°C
Cushioning length 1.5 mm
Product weight 176 g
Type of mounting With through-hole
Pneumatic connection M5
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy
Material seals HNBR
Material guide POM TPE-E High-alloy steel
Material housing Wrought aluminium alloy
Material piston rod High-alloy stainless steel



Other size as follow

Type Order no Weight(g) Price
DGST-8-10-E1A 8078833 129 USD300-350
DGST-8-20-E1A 8078834 154 USD300-350
DGST-8-30-E1A 8078835 176 USD300-350
DGST-8-40-E1A 8078836 200 USD300-350
DGST-8-50-E1A 8078837 236 USD300-350
DGST-8-80-E1A 8078838 310 USD300-350



Cushing Type

Mini Slide Pneumatic Air Cylinders DGST-8-30-E1A 8078835 GTIN4052568446666



A wide range of products with excellent prices. Please hurry to me!
