| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | DGST-20-100-E1A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD500-550 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 10-15working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 20 pcs per month |
| Type: | DGST-20-100-E1A | Part No: | 8078868 |
|---|---|---|---|
| Brand: | FESTO | GTIN: | 4052568446994 |
| Max. Speed: | 0.5 M/s | Repetition Accuracy: | <= 0.3 Mm |
| High Light: | 0.3mm Pneumatic Air Cylinders,Mini Slide Pneumatic Air Cylinders,Ball Bearing Pneumatic Cylinder |
||
Advantage
1.Space-saving mounting of mini-slides next to one another.
2.The connection kit enables having axial supply ports.
3.Particularly suitable for applications in which no space is available at the side for supply ports.
4.No readjustment required; position is fully maintained under lock and load.
5.Stroke can be reduced to the next smaller standard stroke.
6.Fast and simple adjustment using two tools.
Technical Data
| Stroke | 100 mm |
| Piston diameter | 20 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastomer cushioning, double-sided, stroke not adjustable |
| Mounting position | optional |
| Guide | Ball bearing cage guide |
| Design | Twin piston Yoke Piston rod Slide |
| Position detection | Via proximity switch |
| Symbol | 00991249 |
| Max. speed | 0.5 m/s |
| Repetition accuracy | <= 0.3 mm |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-60°C |
| Cushioning length | 1 mm |
| Product weight | 1962 g |
| Type of mounting | With through-hole |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | HNBR |
| Material guide | POM TPE-E High-alloy steel |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Other size as follow
| Type | Order no | Weight(g) | Price |
| DGST-20-10-E1A | 8078862 | 978 | USD500-550 |
| DGST-20-20-E1A | 8078863 | 986 | USD500-550 |
| DGST-20-30-E1A | 8078864 | 994 | USD500-550 |
| DGST-20-40-E1A | 8078865 | 1055 | USD500-550 |
| DGST-20-50-E1A | 8078866 | 1196 | USD500-550 |
| DGST-20-80-E1A | 8078867 | 1618 | USD500-550 |
| DGST-20-100-E1A | 8078868 | 1962 | USD500-550 |
Dimensions
