| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | DGST-16-80-E1A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD450-500 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 10-15working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 20 pcs per month |
| Type: | DGST-16-80-E1A | Part No: | 8078858 |
|---|---|---|---|
| Brand: | FESTO | GTIN: | 4052568446895 |
| Product Weight: | 930 G | Material Piston Rod: | High-alloy Stainless Steel |
| High Light: | Alloy Stainless Steel Pneumatic Air Cylinders,Mini Slide Compact Air Cylinder,Mini Slide Pneumatic Cylinder |
||
Advantage
1.Elastomer cushioning, at both ends, stroke not adjustable .
2.Enhanced precision.
3.Longer service life.
4.Space-saving mounting of mini-slides next to one another.
5.The connection kit enables having axial supply ports.
6.Particularly suitable for applications in which no space is available at the side for supply ports.
Technical Data
| Stroke | 80 mm |
| Piston diameter | 16 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastomer cushioning, double-sided, stroke not adjustable |
| Mounting position | optional |
| Guide | Recirculating ball bearing guide |
| Design | Twin piston Yoke Piston rod Slide |
| Position detection | Via proximity switch |
| Symbol | 00991249 |
| Max. speed | 0.5 m/s |
| Repetition accuracy | <= 0.3 mm |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-60°C |
| Product weight | 930 g |
| Type of mounting | With through-hole |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | HNBR |
| Material guide | POM TPE-E High-alloy steel |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Other size as follow
| Type | Order no | Weight(g) | Price |
| DGST-16-10-E1A | 8078853 | 454 | USD450-500 |
| DGST-16-20-E1A | 8078854 | 482 | USD450-500 |
| DGST-16-30-E1A | 8078855 | 510 | USD450-500 |
| DGST-16-40-E1A | 8078856 | 629 | USD450-500 |
| DGST-16-50-E1A | 8078857 | 690 | USD450-500 |
| DGST-16-80-E1A | 8078858 | 930 | USD450-500 |
| DGST-16-100-E1A | 8078859 | 1060 | USD450-500 |
Datasheet
