Name: MD MK Series Multi Mount MK16-40 Double Acting Pneumatic Cylinder 1.0MPA
Brand: FLY AUTOMATION
SKU: MK16-40
Price: 1,150.60 USD
Availability: InStock

Home Products Pneumatic Air Cylinders

MD MK Series Multi Mount MK16-40 Double Acting Pneumatic Cylinder 1.0MPA

Product Details:

Place of Origin:	CHINA
Brand Name:	AIRWOLF
Certification:	CE
Model Number:	MK16-40

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Negotiation
Packaging Details:	Plastic bags, boxes, cartons, Pallets or As customer's requirement
Delivery Time:	1-7 work days
Payment Terms:	Western Union, T/T, L/C, Paypal, Credit card
Supply Ability:	2000 pieces per 10 working days

Contact Now

Detailed Product Description

Material:

Aluminum

Acting Type:

Doubel Acting

Proof Pressure:

1.5MPA

Operating Pressure:

0.15 ~1.0MPA

Highlight:

MK16-40 Double Acting Pneumatic Cylinder

MK16-40 Double Acting Air Cylinder

Double Acting Pneumatic Cylinder 1.0MPA

MD,MK Series Multi-mount cylinder MK16-40 Double acting Pneumatic cylinder

Product feature

1. Manufactured by our enterprise

2. There are several fixation ways for the cylinder ,and also convernient to install and use.

3. Several cylinders can be assembled together to effectively save the installation space.

4. The guide precision of piston rod is high and no assitional lubricant is needed,

5. Fixated block is attached to piston rod ,which prevents it ftom rotating.

6. Various cylinders are available for your choice.

7. The seal material with high temperature resistance is adopted to guaranteethe normal operation of cylinder at 150 (Option)

Bore size:		6	10	16	20	25	32
Acting type:	MK/MKD/MKJ	Double Acting
	MSK/MTK	Single Acting
Fluid:		Air(to be filtered by 40μm filter element)
Operating Pressure:	Double Acting:	0.1~1.0MPa(15~145psi)(1.0~10.0bar)
	Single Acting:	0.2~1.0MPa(28~145psi)(2.0~10.0bar)
Proof pressure:		1.5MPa(215psi)
Temperature(℃):		-20~70
Speed rang (mm/s):		Double Acting: 30~500 Single Acting:50~500
Stroke tolerance:		(0~+1.0)
Cushion Type:		Bumper
Port Size:		M5X0.8					PT1/8

Bore size(mm)		Standard Stroke(mm)	Max Stroke(mm)	Allow Stroke(mm)
6	Double Acting:	5 10 15 20 25 30 35	35	40
6	Single Acting:	5 10 15 20	20	-
10	Double Acting:	5 10 15 20 25 30 35	35	40
10	Single Acting:	5 10 15 20	20	-
16	Double Acting:	5 10 15 20 25 30 40 50	50	70
16	Single Acting:	5 10 15 20	20	-
20	Double Acting:	5 10 15 20 25 30 40 50 60	60	80
20	Single Acting:	5 10 15 20	20	-
25	Double Acting:	5 10 15 20 25 30 40 50 60	60	80
25	Single Acting:	5 10 15 20	20	-
32	Double Acting:	5 10 15 20 25 30 40 50 60	60	80
32	Single Acting:	5 10 15 20	20	-

MD MK Series Multi Mount MK16-40 Double Acting Pneumatic Cylinder 1.0MPA

Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNL will be normal ways. If you require use of a courier, we can do it.

Competitive Advantage:

Our product features:	Our Services Guarantee:
1) Competitive price	1) Prompt respond (Reply with 24 hours)
2) Good quality	2) Free Samples (Customer pay for the delivery cost)
3) Professional Packaging,	3) Registration support.
4) Produce according to Customers’ instruction	4) Photos/videos are available during production.
5) None delay shipment	5) Loading inspection, and send loading photos before shipment.

Quality Standards
The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount, but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance, according to the original quality standards, during warranty with product problems, need confirmation testing by the manufacturer, the supplier to be solved, the demand side due to storage, use, poor maintenance caused by lower-quality product, and not raise objections.

Packaging shipping
1. If order is not big enough, we will provide Door To Door service, we cooperate with UPS,DHL,FEDEX,TNT all year round,we gurantee that the shipping price that we offer to you is the most favorable price among so many suppliers in China.
2. By Air or By Sea through your forwarder is acceptable, if you have no forwarder in China, we also could find you cost-effective forwarder for your reference.
