| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | ADN-12-20-I-P-A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD25-35 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100 pcs per month |
| Brand: | FESTO | Type: | ADN-12-20-I-P-A |
|---|---|---|---|
| Part No: | 536214 | GTIN: | 4052568087227 |
| Piston Rod Thread: | M3 | Conforms To Standard: | ISO 21287 |
| High Light: | Double Acting Compact Pneumatic Cylinder,M3 Pneumatic Air Cylinders,Aluminium Compact Air Cylinder |
||
About product
1.ISO 21287
2.Up to 50% less installation space than comparable standards-based cylinders to ISO 15552.
3.Piston rod with female or male thread.
Technical Data
| Stroke | 20 mm |
| Piston diameter | 12 mm |
| Piston rod thread | M3 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Conforms to standard | ISO 21287 |
| Piston-rod end | Female thread |
| Position detection | Via proximity switch |
| Symbol | 00991217 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Basic weight for 0 mm stroke | 77 g |
| Additional weight per 10 mm stroke | 12 g |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Aluminium Anodised |
| Material seals | TPE-U(PUR) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy Smooth anodised |
Another stroke as follow
| Type | Order no | GTIN | Price |
| ADN-12-5-I-P-A | 536211 | 4052568087197 | USD25-35 |
| ADN-12-10-I-P-A | 536212 | 4052568087203 | USD25-35 |
| ADN-12-15-I-P-A | 536213 | 4052568087210 | USD25-35 |
| ADN-12-20-I-P-A | 536214 | 4052568087227 | USD25-35 |
| ADN-12-25-I-P-A | 536215 | 4052568087234 | USD25-35 |
| ADN-12-30-I-P-A | 536216 | 4052568087241 | USD25-35 |
| ADN-12-40-I-P-A | 536217 | 4052568087258 | USD25-35 |
Cushioning
There are so many kinds. Hurry to call me!
