ISO Pneumatic Air Cylinders DSBC-80-300-PPVA-N3 2126600 GTIN4052568252076

Product Details:

Place of Origin:	China
Brand Name:	FESTO
Model Number:	DSBC-80-300-PPVA-N3

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	EXW USD140-150
Packaging Details:	plastic bag, carton，OPP bag
Delivery Time:	10-15 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	50 pcs per month

Contact Now

Detailed Product Description

Type:	DSBC-80-300-PPVA-N3	Part No:	2126600
Brand:	FESTO	GTIN:	4052568252076
Piston Rod Thread:	M20x1.5	Piston Diameter:	80mm
High Light:	ISO Pneumatic Air Cylinders , 2126600 Pneumatic Air Cylinders , 80mm Compact Pneumatic Cylinder

FESTO ISO cylinder DSBC-80-300-PPVA-N3 2126600 GTIN4052568252076 Pneumatic Air Cylinders

Name: ISO Pneumatic Air Cylinders DSBC-80-300-PPVA-N3 2126600 GTIN4052568252076
Brand: FESTO
SKU: DSBC-80-300-PPVA-N3
Price: 140 USD
Availability: InStock
Rating: 4.9 (191 reviews)

Advantage

1.With protection against rotation.

2.Low friction.

3.Constant, slow movement.

4.Low friction for balancer applications.

Technical Data

Stroke	300mm
Piston diameter	80mm
Piston rod thread	M20x1.5
Cushioning	Pneumatic cushioning, adjustable at both ends
Mounting position	optional
Conforms to standard	ISO 15552
Piston-rod end	Male thread
Design	Piston Piston rod Profile barrel
Position detection	Via proximity switch
Symbol	00991235
Variants	Piston rod at one end
Mode of operation	Double-acting
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-20°C-80°C
Cushioning length	31mm
Basic weight for 0 mm stroke	2660 g
Additional weight per 10 mm stroke	92 g
Type of mounting	Via female thread With accessories Either:
Pneumatic connection	G3/8
Note on materials	RoHS-compliant
Material cover	Die-cast aluminium, coated
Material piston seal	TPE-U(PU)
Material piston	Wrought aluminium alloy
Material piston rod	High-alloy steel
Material piston rod wiper	TPE-U(PU)
Buffer seal material	TPE-U(PU)
Cushioning piston material	POM
Material cylinder barrel	Smooth-anodised wrought aluminium alloy
Material nut	Galvanised steel
Material bearing	POM
Material collar screws	Galvanised steel

Other size as below

Type	Order no	Weight(g)	Price
DSBC-80-20-PPVA-N3	2126594	2844	USD140-150
DSBC-80-25-PPVA-N3	1383333	2890	USD140-150
DSBC-80-30-PPVA-N3	2126595	2936	USD140-150
DSBC-80-40-PPVA-N3	1383334	3028	USD140-150
DSBC-80-50-PPVA-N3	1383335	3120	USD140-150
DSBC-80-60-PPVA-N3	2126597	3212	USD140-150
DSBC-80-70-PPVA-N3	2126598	3304	USD140-150
DSBC-80-80-PPVA-N3	1383336	3396	USD140-150
DSBC-80-100-PPVA-N3	1383337	3580	USD140-150
DSBC-80-125-PPVA-N3	1383338	3810	USD140-150
DSBC-80-150-PPVA-N3	2126599	4040	USD140-150
DSBC-80-160-PPVA-N3	1383339	4132	USD140-150
DSBC-80-200-PPVA-N3	1383340	4500	USD140-150
DSBC-80-250-PPVA-N3	1383341	4960	USD140-150
DSBC-80-300-PPVA-N3	2126600	5420	USD140-150
DSBC-80-320-PPVA-N3	1383342	5604	USD140-150
DSBC-80-400-PPVA-N3	1383343	6340	USD140-150
DSBC-80-500-PPVA-N3	1383344	7260	USD140-150
