Guided Drive Pneumatic Air Cylinders DFM-16-80-B-PPV-A-KF 559463 GTIN4052568362669

Guided Drive Pneumatic Air Cylinders DFM-16-80-B-PPV-A-KF 559463 GTIN4052568362669

  • Guided Drive Pneumatic Air Cylinders DFM-16-80-B-PPV-A-KF 559463 GTIN4052568362669
  • Guided Drive Pneumatic Air Cylinders DFM-16-80-B-PPV-A-KF 559463 GTIN4052568362669
  • Guided Drive Pneumatic Air Cylinders DFM-16-80-B-PPV-A-KF 559463 GTIN4052568362669
Guided Drive Pneumatic Air Cylinders DFM-16-80-B-PPV-A-KF 559463 GTIN4052568362669
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: DFM-16-80-B-PPV-A-KF
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD50-60
Packaging Details: Plastic bag, Carton
Delivery Time: 7-10working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 100 pcs per month
Contact Now
Detailed Product Description
Part No: 559463 Type: DFM-16-80-B-PPV-A-KF
Brand: FESTO Stroke: 80 Mm
Mounting Position: Optional Design: Guidance
Highlight:

Guided Drive Pneumatic Air Cylinders

,

80 Mm Compact Pneumatic Cylinder

,

Alloy Stainless Steel Air Piston Cylinder

FESTO Guided drive DFM-16-80-B-PPV-A-KF 559463 GTIN4052568362669

About product

1.High resistance to torques and lateral forces.

2.Drive and guide unit in a single housing.

3.Plain or recirculating ball bearing guide.





Technical Data

Stroke 80 mm
Piston diameter 16 mm
Operating mode, drive unit Yoke
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position optional
Guide Recirculating ball bearing guide
Design Guidance
Position detection Via proximity switch
Operating pressure 0.2 MPa ... 1 MPa
Operating pressure 2 bar ... 10 bar
Mode of operation Double-acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC 0 - No corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Pneumatic connection M5
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy
Material seals NBR
Material housing Wrought aluminium alloy
Material piston rod High-alloy stainless steel



Package  picture

Guided Drive Pneumatic Air Cylinders DFM-16-80-B-PPV-A-KF 559463 GTIN4052568362669Guided Drive Pneumatic Air Cylinders DFM-16-80-B-PPV-A-KF 559463 GTIN4052568362669
