| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | DGST-10-20-E1A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD350-400 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 10-15working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 20 pcs per month |
| Part No: | 8078840 | Type: | DGST-10-20-E1A |
|---|---|---|---|
| Brand: | FESTO | GTIN: | 4052568446710 |
| Max. Speed: | 0.5 M/s | LABS (PWIS) Conformity: | VDMA24364-B2-L |
| High Light: | Mini Slide Air Pneumatic Cylinder,8078840 Air Pneumatic Cylinder,0.5m/s Compact Air Cylinder |
||
About Product
1.Excellent value for money.
2.High feed forces.
3.Symmetrical mounting interfaces.
4.Precise and resilient roller bearing guide.
5.Simple design with symmetrical mounting interfaces.
6.Can be operated without additional cushioning components.
Technical Data
| Stroke | 20 mm |
| Piston diameter | 10 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastomer cushioning, double-sided, stroke not adjustable |
| Mounting position | optional |
| Guide | Recirculating ball bearing guide |
| Design | Twin piston Yoke Piston rod Slide |
| Position detection | Via proximity switch |
| Symbol | 00991249 |
| Max. speed | 0.5 m/s |
| Repetition accuracy | <= 0.3 mm |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-60°C |
| Product weight | 254 g |
| Type of mounting | With through-hole |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | HNBR |
| Material guide | POM TPE-E High-alloy steel |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Other size as follow
| Type | Order no | Weight(g) | Price |
| DGST-10-10-E1A | 8078839 | 247 | USD350-400 |
| DGST-10-20-E1A | 8078840 | 254 | USD350-400 |
| DGST-10-30-E1A | 8078841 | 292 | USD350-400 |
| DGST-10-40-E1A | 8078842 | 324 | USD350-400 |
| DGST-10-50-E1A | 8078843 | 359 | USD350-400 |
| DGST-10-80-E1A | 8078844 | 501 | USD350-400 |
| DGST-10-100-E1A | 8078845 | 561 | USD350-400 |
Application examples
A wide range of products with excellent prices. Please hurry to me!
