GTIN4052568418007 Pneumatic Air Cylinders Guided Drive DFM-6-5-P-A-GF 4149944

GTIN4052568418007 Pneumatic Air Cylinders Guided Drive DFM-6-5-P-A-GF 4149944

  • GTIN4052568418007 Pneumatic Air Cylinders Guided Drive DFM-6-5-P-A-GF 4149944
  • GTIN4052568418007 Pneumatic Air Cylinders Guided Drive DFM-6-5-P-A-GF 4149944
GTIN4052568418007 Pneumatic Air Cylinders Guided Drive DFM-6-5-P-A-GF 4149944
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: DFM-6-5-P-A-GF
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD40-50
Packaging Details: Plastic bag, Carton，OPP bag
Delivery Time: 10-15working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 80 pcs per month
Contact Now
Detailed Product Description
Part No: 4149944 Type: DFM-6-5-P-A-GF
Brand: FESTO GTIN: 4052568418007
Design: Guidance Symbol: '00991737
Highlight:

Guidance Compact Pneumatic Cylinder

,

4149944 Pneumatic Air Cylinders

,

Guided Drive DFM-6-5-P-A-GF

FESTO Guided drive DFM-6-5-P-A-GF 4149944 GTIN4052568418007 Pneumatic Air Cylinders

About Product

1.Drive and guide unit in a single housing.

2.High resistance to torques and lateral forces.

3.Plain or recirculating ball bearing guide.



Technical Data

Stroke 5 mm
Piston diameter 6 mm
Operating mode, drive unit Yoke
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Guide Plain-bearing guide
Design Guidance
Position detection Via proximity switch
Symbol 00991737
Max. speed 1.3 m/s
Mode of operation Double-acting
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -10°C-60°C
Product weight 28 g
Pneumatic connection M3
Note on materials RoHS-compliant
Material cover High-alloy stainless steel
Material seals NBR
Material dynamic seals HNBR
Material end plate Anodised wrought aluminium alloy
Material guide rod High-alloy stainless steel
Material housing Anodised wrought aluminium alloy
Material piston rod High-alloy stainless steel



Other size as follow:

Type Order no Weight(g) Price
DFM-6-5-P-A-GF 4149944 28 USD40-50
DFM-6-10-P-A-GF 4149945 33 USD40-50
DFM-6-15-P-A-GF 4149946 40 USD40-50
DFM-6-20-P-A-GF 4149947 45 USD40-50



Cushioning type
