GTIN4052568128807 Flat Pneumatic Air Cylinders DZF-32-100-A-P-A 161268

GTIN4052568128807 Flat Pneumatic Air Cylinders DZF-32-100-A-P-A 161268

  • GTIN4052568128807 Flat Pneumatic Air Cylinders DZF-32-100-A-P-A 161268
  • GTIN4052568128807 Flat Pneumatic Air Cylinders DZF-32-100-A-P-A 161268
GTIN4052568128807 Flat Pneumatic Air Cylinders DZF-32-100-A-P-A 161268
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: DZF-32-100-A-P-A
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD150-180
Packaging Details: Plastic bag, Carton，OPP bag
Delivery Time: 7-10working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 100 pcs per month
Contact Now
Detailed Product Description
Part No: 161268 Brand: FESTO
Type: DZF-32-100-A-P-A Stroke: 100 Mm
Material Piston Rod: High-alloy Steel Material Housing: Aluminium Smooth Anodised
Highlight:

Flat Pneumatic Air Cylinders

,

Aluminium Smooth Anodised Flat Cylinder

,

161268 Pneumatic Air Cylinders

FESTO Flat cylinder DZF-32-100-A-P-A 161268 GTIN4052568128807 Pneumatic Air Cylinders

About product

1.Extremely flat design.

2.Protected against rotation thanks to special piston shape.

3.Ideal for manifold assembly.

4.Special shape piston rod is adopted to resist torsion.

5.Modular installation, compact space.

6.Multiple installation methods.



Technical Data

Piston diameter 32 mm Equivalent diameter
Mounting position optional
Mode of operation Double-acting
Design Piston Piston rod
Position detection Via proximity switch
Symbol 00991217
Protection against torque/guide Oval piston
Operating pressure 0.1 MPa ... 1 MPa
Operating pressure 1 bar ... 10 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Basic weight for 0 mm stroke 272 g
Type of mounting Either: Via female thread With accessories
Pneumatic connection G1/8
Material cover Wrought aluminium alloy
Material seals NBR TPE-U(PU)
Material housing Aluminium Smooth anodised
Material piston rod High-alloy steel





Product picture

GTIN4052568128807 Flat Pneumatic Air Cylinders DZF-32-100-A-P-A 161268GTIN4052568128807 Flat Pneumatic Air Cylinders DZF-32-100-A-P-A 161268



A wide range of products with excellent prices. Please hurry to me!
