| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | VUVG-B10-M52-RZT-F-1T1L |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD50-60 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100 pcs per month |
| Order No: | 573416 | Brand: | FESTO |
|---|---|---|---|
| Model: | VUVG-B10-M52-RZT-F-1T1L | Material Housing: | Wrought Aluminium Alloy |
| Type Of Actuation: | Electric | Valve Size: | 10 Mm |
| High Light: | Aluminium Alloy Pneumatic Solenoid Valves,573416 Air Solenoid Valve,10mm Air Operated Solenoid Valve |
||
About product
1.Sub-base valve, semi in-line valve.
2.For valve terminal VTUG with multi-pin, fieldbus interface.
3.Variants to EU Explosion Protection Directive (ATEX).
Technical Data
| Valve function | 5/2-way, monostable |
| Type of actuation | Electric |
| Valve size | 10 mm |
| Standard nominal flow rate | 220 l/min |
| pneumatic working port | Flange |
| Operating voltage | 24V DC |
| Design | Piston gate valve |
| Type of reset | Mechanical spring Pneumatic spring |
| Approval | c UL us - Recognized (OL) |
| Degree of protection | IP65 IP67 |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Detenting Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | External |
| Flow direction | Reversible |
| Symbol | 00992849 |
| lap | Positive overlap |
| Signal status display | LED |
| Max. switching frequency | 3 Hz |
| Switching time off | 21 ms |
| Switching time on | 9 ms |
| Duty cycle | 100% |
| Characteristic coil data | 22 V DC: 1.0 W |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -5°C-60°C |
| Pilot medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -5°C-60°C |
| Product weight | 53 g |
| Electrical connection | Via sub-base |
| Type of mounting | On manifold rail |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Wrought aluminium alloy |
Another size
| Type | Order no | Price |
| VUVG-B10Z-M32C-RZT-F-1T1L | 8028231 | USD50-60 |
| VUVG-B10Z-M32U-RZT-F-1T1L | 8028232 | USD50-60 |
| VUVG-B10-T32C-AZT-F-1T1L | 573410 | USD50-60 |
| VUVG-B10-T32U-AZT-F-1T1L | 573411 | USD50-60 |
| VUVG-B10-T32H-AZT-F-1T1L | 573412 | USD50-60 |
| VUVG-B10-T32C-MZT-F-1T1L | 573413 | USD50-60 |
| VUVG-B10-T32U-MZT-F-1T1L | 573414 | USD50-60 |
| VUVG-B10-T32H-MZT-F-1T1L | 573415 | USD50-60 |
| VUVG-B10-M52-MZT-F-1T1L | 573417 | USD50-60 |
| VUVG-B10-M52-RZT-F-1T1L | 573416 | USD50-60 |
| VUVG-B10-B52-ZT-F-1T1L | 573418 | USD50-60 |
| VUVG-B10-P53C-ZT-F-1T1L | 573419 | USD50-60 |
| VUVG-B10-P53U-ZT-F-1T1L | 573421 | USD50-60 |
| VUVG-B10-P53E-ZT-F-1T1L | 573420 | USD50-60 |
There are so many products, welcome to enquire!
