| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | QSL-G3/8-10 |
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | EXW USD3-4 |
| Packaging Details: | plastic bag, carton |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 8000 pcs per week |
| Order No: | 186123 | Colour Of Release Ring: | Blue |
|---|---|---|---|
| Specifications: | QSL-G3/8-10 | Brand: | FESTO |
| Product Weight: | 33 G | Material Housing: | PBT |
| High Light: | Pneumatic Tube Fittings QSL-G3/8-10,186123 Push In L Fitting,PBT Push In L Fitting |
||
About product
Type of seal on screw-in stud:Sealing ring
Design:L-shape
Colour of release ring:Blue
Product Technical Data
| Size | Standard |
| Nominal size | 8.3 mm |
| Type of seal on screw-in stud | Sealing ring |
| Mounting position | optional |
| Design | L-shape |
| Size of pack | 10 |
| Design | Push-pull principle |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-80°C |
| Product weight | 33 g |
| Type of mounting | External hexagon, A/F 20 mm |
| Pneumatic connection, port 1 | Male thread G3/8 |
| Pneumatic connection, port 2 | For tubing outside diameter of 10 mm |
| Colour of release ring | Blue |
| Note on materials | RoHS-compliant |
| Material housing | PBT |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
There are so many models.Welcome to enquiry and contact with me.Wait for you!
Contact Person: Jaren
Tel: 0086-15257858856
Fax: 86-152-57858856
