| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | QSL-1/4-8 |
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | EXW USD2-3 |
| Packaging Details: | plastic bag, carton |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 8000 pcs per week |
| Order No: | 153049 | Specifications: | QSL-1/4-8 |
|---|---|---|---|
| Brand: | FESTO | Product Weight: | 20 G |
| Corrosion Resistance Class CRC: | 1 - Low Corrosion Stress | LABS (PWIS) Conformity: | VDMA24364-B1/B2-L |
| High Light: | 153049 Pneumatic Tube Fittings,QSL-1/4-8,Pneumatic Push-In L-Fitting |
||
About product
1.Material tubing clamp component:High-alloy stainless steel.
2.Wide selection of push-in fittings for pneumatic applications with a temperature range up to 80°C and a pressure range up to 14 bar.
3.Colour of release ring:Blue.
Product Technical Data
| Size | Standard |
| Nominal size | 6.7 mm |
| Type of seal on screw-in stud | Coating |
| Mounting position | optional |
| Size of pack | 10 |
| Design | Push-pull principle |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-80°C |
| Product weight | 20 g |
| Pneumatic connection, port 1 | Male thread R1/4 |
| Pneumatic connection, port 2 | For tubing outside diameter of 8 mm |
| Colour of release ring | Blue |
| Note on materials | RoHS-compliant |
| Material housing | PBT |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
Datasheet
There are so many models, best price and fast delivery time. Welcome to enquiry and contact with me.Wait for you!
