FESTO Solenoid Valve CPV14-M1H-2X3-GLS-1/8 161362 Pneumatic Solenoid Valves

FESTO Solenoid Valve CPV14-M1H-2X3-GLS-1/8 161362 Pneumatic Solenoid Valves

  • FESTO Solenoid Valve CPV14-M1H-2X3-GLS-1/8 161362 Pneumatic Solenoid Valves
  • FESTO Solenoid Valve CPV14-M1H-2X3-GLS-1/8 161362 Pneumatic Solenoid Valves
  • FESTO Solenoid Valve CPV14-M1H-2X3-GLS-1/8 161362 Pneumatic Solenoid Valves
FESTO Solenoid Valve CPV14-M1H-2X3-GLS-1/8 161362 Pneumatic Solenoid Valves
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: CPV14-M1H-2X3-GLS-1/8
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD50-60
Packaging Details: Plastic bag, Carton
Delivery Time: 10-15 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000 pcs per month
Contact Now
Detailed Product Description
Type: CPV14-M1H-2X3-GLS-1/8 Brand: FESTO
Part No: 161362 Valve Function: 2x3/2-way, Monostable, Closed
Type Of Actuation: Electric Operating Voltage: 24V DC
Highlight:

CPV14-M1H-2X3-GLS-1/8

,

161362 Pneumatic Solenoid Valves

FESTO Solenoid valve CPV14-M1H-2X3-GLS-1/8 161362 Pneumatic Solenoid Valves

About product

Cubic design for exceptional performance and low weight

Low installation and bus connection costs

Integrated diagnostics, condition monitoring (Fieldbus Direct)

Separator plates for creating pressure zones

Valves with integrated separation of ducts 1 and 11

Blanking plates for later extensions



Technical Data

Valve function 2x3/2-way, monostable, closed
Type of actuation Electric
Valve size 14 mm
Operating voltage 24V DC
Symbol 00991808
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Product weight 120 g
Note on materials RoHS-compliant
Material seals HNBR NBR
Material housing Die-cast aluminium Brass POM PPS Steel



There are so many models . Please contact with me!
