FESTO Pneumatic Tube Fittings Push In T Fitting CRQST-3/8-10 164206 4052568136918

Product Details:

Place of Origin:	China
Brand Name:	FESTO
Model Number:	CRQST-3/8-10

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	EXW USD30-40
Packaging Details:	Carton，OPP bag
Delivery Time:	7-10 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	80 pcs per week

Contact Now

Detailed Product Description

Nominal Size:	5.9 Mm	Order No:	164206
Brand:	FESTO	GTIN:	4052568136918
Specifications:	CRQST-3/8-10	Weight:	62g
Size Of Pack:	1	Material Housing:	High-alloy Stainless Steel
Highlight:	Pneumatic Push In T Fitting , 164206 Pneumatic Tube Fittings , 5.9mm Tube T Fitting

FESTO,Push-in T-fitting,CRQST-3/8-10,164206,4052568136918,Pneumatic Tube Fittings

Name: FESTO Pneumatic Tube Fittings Push In T Fitting CRQST-3/8-10 164206 4052568136918
Brand: FLY AUTOMATION
SKU: CRQST-3/8-10
Price: 35.00 USD
Availability: InStock

Nominal size:5.9mm

Order no:164206

Brand:FESTO

GTIN:4052568136918

Specifications:CRQST-3/8-10

Weight:62g

Size of pack:1

Material housing:High-alloy stainless steel

Product Technical Data

Feature	Value
Size	Standard
Nominal size	5.9mm
Mounting position	optional
Size of pack	1
Design	Push-pull principle
Note on operating and pilot medium	Lubricated operation possible
Corrosion resistance class CRC	4 - Very high corrosion stress
Product weight	62g
Number of outputs	2
Number of supply lines	1
Material housing	High-alloy stainless steel
Material release ring	High-alloy stainless steel
Material tubing seal	FPM
Material tubing clamp component	High-alloy stainless steel
Note on materials	RoHS-compliant
Suitable cables	PFAN

Another size as follow

Specifications	Order NO	GTIN	Weight(g)	EXW Price	Size of pack
CRQST-1/4-8	164204	4052568073244	38	USD30-40	1
CRQST-1/4-10	164205	4052568136901	56	USD30-40	1
CRQST-1/8-6	164202	4052568073220	25	USD30-40	1
CRQST-1/8-8	164203	4052568073237	33	USD30-40	1
CRQST-3/8-10	164206	4052568136918	62	USD30-40	1
CRQST-1/8-8	164203	4052568073237	85	USD30-40	1
CRQST-1/2-12	164208	4052568136932	105	USD30-40	1
CRQST-1/2-16	164209	4052568136949	128	USD35-45	1

Orientable Male thread with external hex

FESTO Pneumatic Tube Fittings Push In T Fitting CRQST-3/8-10 164206 4052568136918

Sectional view

FESTO Pneumatic Tube Fittings Push In T Fitting CRQST-3/8-10 164206 4052568136918

About product

1.Simply "plug and work".

2.Reliably connected.

3.Orientable.

4.Highest process reliability in every case

5.Unlimited use in the food industry

6.Corrosion resistance CRC 4 and chemical resistance with approval for use in the food and packaging industry.

7.For pneumatic applications with a temperature range up to 120 °C and a pressure range up to 10 bar.

8.Joints with different thread specifications are often used between pipelines to complete the connection.

Competitive Advantage

Our product features: Our Services Guarantee:

1) Competitive price 1) Prompt respond (Reply with 24 hours)

2) Good quality 2) Free Samples (Customer pay for the delivery cost)

3) Professional Packaging, 3) Registration support.

4) Produce according to Customers’ instruction 4) Photos/videos are available during production.

5) None delay shipment

5) Loading inspection, and send loading photos before shipment.

After-sale Service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.

There are many specifications of connectors, price and delivery time. Welcome to inquire.
