| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | VUVG-L14-M52-A-G18-P1 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD50-80 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 5-7working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 600 pcs per month |
| Type: | VUVG-L14-M52-A-G18-P1 | Part No: | 8033529 |
|---|---|---|---|
| Brand: | FESTO | Weight: | 66 G |
| Valve Function: | 5/2-way, Monostable | Type Of Actuation: | Electric |
| High Light: | VUVG-L14-M52-A-G18-P1 Pneumatic Solenoid Valves,5/2-Way Festo Solenoid Valve,Wall Mounting Pneumatic Solenoid Valves |
||
About product
1.Secure wall mounting or H-rail mounting.
2.Easy mounting, captive screws and seal.
3.Connection technology easy to change via the electrical sub-base.
4.Identification holder for labelling the valves.
5.The electrical connection is established via different E-boxes.
Technical Data
| Valve function | 5/2-way, monostable |
| Type of actuation | Electric |
| Valve size | 14 mm |
| Standard nominal flow rate | 700 l/min ... 780 l/min |
| pneumatic working port | G1/8 |
| Operating pressure | 0.25 MPa ... 0.8 MPa |
| Operating pressure | 2.5 bar ... 8 bar |
| Design | Piston gate valve |
| Type of reset | Pneumatic spring |
| Approval | c UL us - Recognized (OL) |
| Certificate issuing authority | UL MH19482 |
| Degree of protection | IP65 With electric pilot valve and plug socket |
| Nominal size | 5.6 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Symbol | 00992908 |
| lap | Positive overlap |
| Pilot pressure | 0.25 MPa ... 0.8 MPa |
| Pilot pressure | 2.5 bar ... 8 bar |
| Suitability for vacuum | no |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -5°C-60°C |
| Ambient temperature | -5°C-60°C |
| Product weight | 66 g |
| Electrical connection | Via electric pilot valve |
| Type of mounting | Either: On manifold rail With through-hole |
| Pneumatic connection, port 1 | G1/8 |
| Pneumatic connection, port 2 | G1/8 |
| Pneumatic connection, port 3 | G1/8 |
| Pneumatic connection, port 4 | G1/8 |
| Pneumatic connection, port 5 | G1/8 |
| Pilot control interface | To ISO 15218 |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Wrought aluminium alloy |
Product package
There are many models. Welcome to contact me!
