FESTO Pneumatic Solenoid Valves VMPA2-M1BH-M-PI 8022034 GTIN4052568257309

Product Details:

Place of Origin:	China
Brand Name:	FESTO
Model Number:	VMPA2-M1BH-M-PI

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	EXW USD60-80
Packaging Details:	Plastic bag, Carton
Delivery Time:	5-7 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	300 pcs per month

Contact Now

Detailed Product Description

Order No:	8022034	Model:	VMPA2-M1BH-M-PI
Brand:	FESTO	Product Weight:	100 G
Material Housing:	Die-cast Aluminium	Note On Materials:	RoHS-compliant
Highlight:	VMPA2-M1BH-M-PI Pneumatic Solenoid Valves , 8022034 Pneumatic Solenoid Valves , Aluminium Air Operated Solenoid Valve

FESTO Solenoid valve VMPA2-M1BH-M-PI 8022034 GTIN4052568257309

Name: FESTO Pneumatic Solenoid Valves VMPA2-M1BH-M-PI 8022034 GTIN4052568257309
Brand: FLY AUTOMATION
SKU: VMPA2-M1BH-M-PI
Price: 70.00 USD
Availability: InStock

About product

1.High pressure range :–0.09 ... +1 MPa .

2.Wide range of valve functions.

3.Secure wall mounting.

4.MPA2 (width 20 mm).

Advantage

1.Easy to service thanks to replaceable valves and electronic modules .

2.Manual override either non-detenting, detenting or secured against unauthorised activation (concealed).

3.Fast troubleshooting thanks to LEDs on the valves .

4.Extensive operating voltage range ±25%.

5.Compact high-performance valves in sturdy metal housing.

6.The valves are identical to the valves in the valve terminal MPA-S and MPA-L. This simplifies planning, ordering and warehousing.

Technical Data

Valve function	5/2-way, monostable
Type of actuation	Electric
Valve size	20 mm
Standard nominal flow rate	870 l/min
Operating voltage	24V DC
Operating pressure	-0.09 MPa ... 1 MPa
Operating pressure	-0.9 bar ... 10 bar
Design	Piston gate valve
Type of reset	Pneumatic spring
Approval	c UL us - Recognized (OL)
Degree of protection	IP65 To IEC 60529
Sealing principle	Soft
Mounting position	optional
Manual override	Detenting Non-detenting
Type of piloting	Pilot actuated
Flow direction	Reversible
Symbol	00991050
lap	Positive overlap
Signal status display	yes
Pilot pressure	0.3 MPa ... 0.8 MPa
Pilot pressure	3 bar ... 8 bar
Suitability for vacuum	yes
Standard nominal flow rate with QS-10	870 l/min
Switching time off	28 ms
Switching time on	15 ms
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Max. tightening torque for valve mounting	0.65 Nm
Product weight	100 g
Type of mounting	With through-hole
Note on materials	RoHS-compliant
Material seals	NBR
Material housing	Die-cast aluminium

Picture about packages

FESTO Pneumatic Solenoid Valves VMPA2-M1BH-M-PI 8022034 GTIN4052568257309

There are so many products, welcome to enquire!
