| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | MHE4-M1H-3/2G-QS-8 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD120-150 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 200 pcs per month |
| Model: | MHE4-M1H-3/2G-QS-8 | Order No: | 525190 |
|---|---|---|---|
| Brand: | FESTO | Weight: | 270g |
| Max. Switching Frequency: | 120 Hz | Construction Width: | 18 Mm |
| High Light: | Galvanised Steel Solenoid Air Valve,525190 Pneumatic Solenoid Valves,3/2-Way Festo Solenoid Valve |
||
About product
1.Pneumatic connection: push-in connector for tubing O.D. 8 mm.
2.Normally closed.
3.Simple to retrofit in existing systems, or setting the pace for newly designed systems. Naturally compact, including maximum component density. 4.Indispensable for sorting parts using an air ejector, in flap control systems, for gluing, dispensing, packaging and, of course, also suitable for pick & place vacuum applications, for example (continuous holding not possible).
Technical Data
| Valve function | 3/2-way, closed, monostable |
| Type of actuation | Electric |
| Construction width | 18 mm |
| Standard nominal flow rate | 400 l/min |
| pneumatic working port | QS-8 |
| Operating voltage | 24V DC |
| Design | Pressure-relieved poppet valve |
| Type of reset | Mechanical spring |
| Degree of protection | IP65 |
| Approval | c UL us - Recognized (OL) |
| Nominal size | 4 mm |
| Grid dimension | 24 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Non-detenting |
| Type of piloting | Direct |
| Flow direction | Reversible with restrictions |
| Symbol | 00991308 |
| lap | Underlap |
| Max. switching frequency | 120 Hz |
| Switching time off | 5 ms |
| Switching time on | 10.5 ms |
| Duty cycle | 100% |
| Characteristic coil data | 24 V DC: 5.6 W |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -5°C-60°C |
| Ambient temperature | -5°C-60°C |
| Product weight | 270 g |
| Electrical connection | 2-pin Plugs |
| Type of mounting | With through-hole |
| Pneumatic connection, port 1 | QS-8 |
| Pneumatic connection, port 2 | QS-8 |
| Pneumatic connection, port 3 | QS-8 |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Die-cast zinc, coated |
| Material screws | Galvanised steel |
Another size as below
| Type | Order no | Price |
| MHE4-MS1H-3/2O-1/4 | 525207 | USD120-150 |
| MHE4-MS1H-3/2G-1/4 | 525187 | USD120-150 |
| MHE4-MS1H-3/2O-QS-8 | 525211 | USD120-150 |
| MHE4-MS1H-3/2G-QS-8 | 525191 | USD120-150 |
| MHE4-M1H-3/2O-1/4 | 525206 | USD120-150 |
| MHE4-M1H-3/2G-1/4 | 525186 | USD120-150 |
| MHE4-M1H-3/2O-QS-8 | 525210 | USD120-150 |
| MHE4-M1H-3/2G-QS-8 | 525190 | USD120-150 |
| MHE4-MS1H-3/2G-1/4-K | 525189 | USD120-150 |
| MHE4-MS1H-3/2O-QS-8-K | 525213 | USD120-150 |
| 3 MHE4-MS1H-3/2G-QS-8-K | 525193 | USD120-150 |
| MHE4-M1H-3/2O-1/4-K | 525208 | USD120-150 |
| MHE4-M1H-3/2G-1/4-K | 525188 | USD120-150 |
There are so many products, welcome to enquire!
