| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | AMTE-M-LH-G18 |
| Minimum Order Quantity: | 1 PC |
|---|---|
| Price: | EXW USD2-3 |
| Packaging Details: | plastic bag, carton |
| Delivery Time: | 5-7working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1000 PCS per month |
| Order No: | 1205860 | Specifications: | AMTE-M-LH-G18 |
|---|---|---|---|
| Brand: | FESTO | Size Of Pack: | 20 |
| Note On Materials: | RoHS-compliant | Weight: | 7.5 G |
| High Light: | Pneumatic Air Cylinders Silencer,Metal Pneumatic Silencer,1205860 Brass Pneumatic Silencer |
||
About product
1.Long design.
2.Metal version.
3.Operating medium compressed air.
4.Suitable for reducing noise at the exhaust ports of pneumatic systems.
5.Material screw-in stud:brass
Technical Data
| Mounting position | optional |
| Size of pack | 20 |
| Symbol | 00991473 |
| Operating pressure | 0 MPa ... 1 MPa |
| Operating pressure | 0 bar ... 10 bar |
| Flow rate to atmosphere | 1735 l/min |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Sound pressure level | 76 dB(A) |
| Ambient temperature | -40°C-80°C |
| Product weight | 7.5 g |
| Pneumatic connection | G1/8 |
| Material shock absorber insert | Bronze |
| Material screw-in stud | Brass |
| Note on materials | RoHS-compliant |
Other size as below
| ORDER NO | TYPE |
| 1231120 | AMTE-M-LH-M3 |
| 1205858 | AMTE-M-LH-M5 |
| 1205860 | AMTE-M-LH-G18 |
| 1205861 | AMTE-M-LH-G14 |
| 1205862 | AMTE-M-LH-G38 |
| 1205863 | AMTE-M-LH-G12 |
| 1205864 | AMTE-M-LH-G34 |
| 1205865 | AMTE-M-LH-G1 |
