| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | HEE-D-MAXI-24 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD80-100 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 500 pcs per month |
| Type: | HEE-D-MAXI-24 | Part No: | 172962 |
|---|---|---|---|
| Brand: | FESTO | Type Of Actuation: | Electric |
| Weight: | 800 G | Material Housing: | Die-cast Aluminium |
| High Light: | HEE-D-MAXI-24,172962 Off Valve,Pneumatic System Festo Off Valve |
||
About product
1.Electric on/off valve for pressurising and exhausting pneumatic systems .
2.With solenoid coil, without plug socket.
3.Choice of three voltage ranges.
4.Ducted exhaust possible via a threaded connection with silencer.
5.Manual override, non-detenting and detenting (using override tool AHB-MD/MF/MV.
6.Solenoid head can be repositioned by 4 x 90°.
7.Electric 3/2-way valve for pressurising and exhausting pneumatic installations.
8.A silencer can be attached or the exhaust air ducted at port 3.
9.With solenoid coil, without plug socket.
Technical Data
| Design | Piston gate valve |
| Type of actuation | Electric |
| Sealing principle | Soft |
| Exhaust-air function | Without flow control option |
| Manual override | Detenting |
| Type of reset | Mechanical spring |
| Type of piloting | Pilot actuated |
| Symbol | 00991008 |
| Valve function | 3/2-way, closed, monostable |
| Operating pressure | 2.5 bar ... 16 bar |
| Characteristic coil data | 24 V DC: 3.0 W |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Note on materials | RoHS-compliant |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -10°C-60°C |
| Ambient temperature | -10°C-60°C |
| Type of mounting | In-line installation With accessories |
| Mounting position | optional |
| Flow direction | Non-reversible |
| Product weight | 800 g |
| Pneumatic connection, port 3 | G3/8 |
| Electrical connection | Type C Plugs To DIN EN 175301-803 |
| Signal status display | With accessories |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
General technical data
Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.
There are many models . Please hurry to me!
