| Brand Name: | FESTO |
| Model Number: | DSNU-25-35-P-A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD40-50 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1000 pcs per month |
| Brand: | FESTO | Type: | DSNU-25-35-P-A |
|---|---|---|---|
| Part No: | 1908308 | Cleanroom Class: | Class 6 According To ISO 14644-1 |
| Pneumatic Connection: | G1/8 | Material Piston Rod: | High-alloy Stainless Steel |
| High Light: | Pneumatic Cylinder DSNU-25-35-P-A,1908308,FESTO ISO Double Acting Cylinder |
||
About product
Piston-rod end:Male thread
Mode of operation:Double-acting
Cleanroom class:Class 6 according to ISO 14644-1
Material cover:Wrought aluminium alloy Colourless anodised
Material seals:NBR TPE-U(PU)
Technical Data
| Stroke | 35 mm |
| Piston diameter | 25 mm |
| Piston rod thread | M10x1.25 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Conforms to standard | CETOP RP 52 P ISO 6432 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Cylinder barrel |
| Symbol | 00991217 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Cleanroom class | Class 6 according to ISO 14644-1 |
| Ambient temperature | -20°C-80°C |
| Basic weight for 0 mm stroke | 238 g |
| Additional weight per 10 mm stroke | 11 g |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy Colourless anodised |
| Material seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy stainless steel |
| Material cylinder barrel | High-alloy stainless steel |
There are so many models ,please contact with me.
Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.
