| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | DNC-100-160-PPV-A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD200-300 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 10-12 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 50 pcs per month |
| Type: | DNC-100-160-PPV-A | Stroke: | 160mm |
|---|---|---|---|
| Part No: | 163471 | Brand: | FESTO |
| Piston Diameter: | 100 Mm | Mode Of Operation: | Double-acting |
| High Light: | 163471 Pneumatic Air Cylinders,Pneumatic Cushioning ISO Cylinder,DNC-100-160-PPV-A |
||
About product
Conforms to standard:ISO 15552
Piston-rod end:Male thread
Cushioning length:32 mm
Moving mass for 0 mm stroke:1544 g
Material cover:Die-cast aluminium Coated
Technical Data
| Stroke | 160 mm |
| Piston diameter | 100 mm |
| Piston rod thread | M20x1.5 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Conforms to standard | ISO 15552 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 00991235 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Cushioning length | 32 mm |
| Moving mass for 0 mm stroke | 1544 g |
| Additional moving mass per 10 mm stroke | 38 g |
| Type of mounting | Via female thread With accessories |
| Pneumatic connection | G1/2 |
| Note on materials | RoHS-compliant |
| Material cover | Die-cast aluminium Coated |
| Material seals | TPE-U(PU) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy Smooth anodised |
General technical data
There are so many MODELS. Welcome to contact me!
Contact Person: Jaren
Tel: 0086-15257858856
Fax: 86-152-57858856
