| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | ADVU-63-20 -P-A-S2 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD50-80 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 10-12 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 50 pcs per month |
| Part No: | 156017 | Type: | ADVU-63-20 -P-A-S2 |
|---|---|---|---|
| Brand: | FESTO | Stroke: | 20 Mm |
| Piston Diameter: | 63 Mm | Mode Of Operation: | Double-acting |
| High Light: | Compact FESTO Pneumatic Air Cylinders,156017 Pneumatic Air Cylinders |
||
About product
Symbol:'00991219
Corrosion resistance class CRC:2 - Moderate corrosion stress
Pneumatic connection:G1/8
Technical Data
| Stroke | 20 mm |
| Piston diameter | 63 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Mode of operation | Double-acting |
| Piston-rod end | Female thread |
| Design | Piston Piston rod |
| Position detection | Via proximity switch |
| Symbol | 00991219 |
| Variants | Through piston rod |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Pneumatic connection | G1/8 |
| Material collar screws | Galvanised steel |
| Material cover | Wrought aluminium alloy |
| Material dynamic seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy |
Product range overview
There are so many MODELS. Hurry to contact me!
