FESTO Compact Cylinder ADN-16-50-A-P-A 536331 Pneumatic Air Cylinders

FESTO Compact Cylinder ADN-16-50-A-P-A 536331 Pneumatic Air Cylinders

  • FESTO Compact Cylinder ADN-16-50-A-P-A 536331 Pneumatic Air Cylinders
  • FESTO Compact Cylinder ADN-16-50-A-P-A 536331 Pneumatic Air Cylinders
FESTO Compact Cylinder ADN-16-50-A-P-A 536331 Pneumatic Air Cylinders
Product Details:
Brand Name: FESTO
Model Number: ADN-16-50-A-P-A
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 50-80
Packaging Details: Plastic bags,Boxes, Cartons
Delivery Time: 7-10 working days
Payment Terms: T/T , Western Union
Supply Ability: 1000 pcs
Contact Now
Detailed Product Description
Model Code: ADN-16-50-A-P-A Part No: 536331
Brand: FESTO Based On Standard: ISO 21287
Mounting Position: Optional Mode Of Operation: Double-acting
Highlight:

ADN-16-50-A-P-A

,

536331 FESTO Compact Cylinder

,

Pneumatic Air Cylinders Double Acting

FESTO Compact cylinder ADN-16-50-A-P-A 536331 Pneumatic Air Cylinders



About Product

Highly flexible thanks to the wide range of variants

Contactless position sensing using proximity switches

Easy to mount with a comprehensive range of mounting accessories for just about every type of installation



Technical data

Stroke 50 mm
Piston diameter 16 mm
Piston rod thread M6
Based on standard ISO 21287
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Mode of operation Double-acting
Piston-rod end Male thread
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 6 according to ISO 14644-1
Ambient temperature -20°C-80°C
Basic weight for 0 mm stroke 79 g
Additional weight per 10 mm stroke 14 g
Pneumatic connection M5
Note on materials RoHS-compliant
Material collar screws Steel
Material cover Anodised wrought aluminium alloy
Material seals TPE-U(PUR)
Material piston rod High-alloy steel
Material cylinder barrel Smooth-anodised wrought aluminium alloy





There are so many models ,please contact with me.
